| Ref | Part Number | Description |
|---|
| 1 |
0390619 |
HOUSING & PIN, Johnson |
| 1 |
0392907 |
HOUSING & PIN, Johnson |
| 2 |
0432544 |
MOUNTING BRACKET This part replaces 0388704. |
| 3 |
0316450 |
SCREW, Adaptor, lower |
| 4 |
0320504 |
SCREW, Bracket to carburetor |
| 5 |
0316449 |
SUPPORT, Bracket to head |
| 6 |
0316497 |
SCREW, Bracket to head |
| 7 |
0314147 |
CHOKE KNOB |
| 8 |
0312890 |
DETENT CHIKE KNOB |
| 9 |
0315258 |
HINGE PIN |
| 10 |
0306544 |
WASHER |
| 10 |
503195920 |
Runner |
| 12 |
0317019 |
SPRING, Throttle detent |
| 13 |
0319168 |
KNOB, Hi & lo speed |
| 14 |
0320405 |
GROMMET, Knob |
| 15 |
0324644 |
SCREW, Solecoid mounting |
| 20 |
503191501 |
Slider Shoe 163 |
| 30 |
208562531 |
Phillips Screw M6 X 25 |
| 40 |
232561434 |
Elastic Stop Nut M6 |
| 45 |
250200140 |
Washer |
| 50 |
503196874 |
Rail Protector This part replaces 503194249. |
| 52 |
207652544 |
Hex. Flange Screw M5 X 25 |
| 55 |
233251434 |
Flanged Elastic Nut M5 |
| 60 |
503192842 |
Front Wheel Shaft |
| 70a |
503190396 |
Ball Bearing |
| 70b |
415129371 |
Retaining Ring |
| 80 |
205505054 |
Socket Screw |
| 90 |
503192496 |
Washer |
| 130 |
503193504 |
Rubber Stopper |
| 150 |
293150224 |
Rivet Pop 3/16 |
| 160 |
503191273 |
Washer |
| 170 |
503195028 |
Rubber Stopper |
| 180 |
293150224 |
Rivet Pop 3/16 |
| 190 |
503191273 |
Washer |
| 440a |
503190396 |
Ball Bearing |
| 440b |
415129371 |
Retaining Ring |
| 441 |
503193894 |
Casted Support |
| 443 |
503191820 |
Wheel Cup M6 |
| 444 |
250000944 |
Hex. Flange Screw M6 X 70 |
| 445 |
233261466 |
Hex. Flanged Elastic Nut M6 |
| 446 |
250000945 |
Hex. Flange Screw M6 X 25 |
| 447 |
233261466 |
Hex. Flanged Elastic Nut M6 |
| 448 |
503195345 |
Black, Wheel Cap |
| 450a |
503190396 |
Ball Bearing |
| 450b |
415129371 |
Retaining Ring |
| 451 |
503193894 |
Casted Support |
| 453 |
503191820 |
Wheel Cup M6 |
| 454 |
250000944 |
Hex. Flange Screw M6 X 70 |
| 455 |
233261466 |
Hex. Flanged Elastic Nut M6 |
| 456 |
250000945 |
Hex. Flange Screw M6 X 25 |
| 457 |
233261466 |
Hex. Flanged Elastic Nut M6 |
| 460a |
503190396 |
Ball Bearing |
| 460b |
415129371 |
Retaining Ring |
| 461 |
503193894 |
Casted Support |
| 463 |
503191820 |
Wheel Cup M6 |
| 464 |
250000944 |
Hex. Flange Screw M6 X 70 |
| 465 |
233261466 |
Hex. Flanged Elastic Nut M6 |
| 466 |
250000945 |
Hex. Flange Screw M6 X 25 |
| 467 |
233261466 |
Hex. Flanged Elastic Nut M6 |
| 1020 |
503195837 |
Limiter Bussing |
| 1030 |
503191260 |
Axle Strap |
| 1040 |
205503554 |
Socket Head Screw M10 X 35 |
| 1045 |
205506044 |
Screw Socket S,Grip M10 X 60 |
| 1050 |
503192496 |
Washer |
| 1090 |
503195775 |
Shock Lower Shaft |
| 1110 |
503192491 |
Washer |
| 1112 |
605449294 |
Support Plate |
| 1113 |
31013 |
Shim Ring |
| 1115 |
605349896 |
Sleeve |
| 1120 |
205525554 |
Socket Screw |
| 3240 |
503192583 |
Tensioner |
| 3245 |
503193250 |
Spacer |
| 3250 |
207063054 |
Hex. Cap Screw M6 X 30 |
| 3260 |
233261466 |
Hex. Flanged Elastic Nut M6 |
| 3270 |
230100054 |
Hex Screw M10 x 100 |
| 3280 |
233601466 |
Elastic Locking Nut M10 |
| 3360 |
503190429 |
Rear Axle |
| 3370 |
250000817 |
Hex Screw With Nilon Patch, M10 X 35 |
| 3380 |
503190439 |
Washer |
| 3391 |
503192771 |
Black, Wheel Cap |
| 3396 |
503190428 |
Rear Wheel Spacer |
| 3400a |
503190396 |
Ball Bearing |
| 3400b |
415129371 |
Retaining Ring |
| 3410a |
503190396 |
Ball Bearing |
| 3410b |
415129371 |
Retaining Ring |
| 3420 |
503196317 |
Spacer |
| 0391783 |
0391783 |
OWNER'S MANUAL, Johnson |
| 0391784 |
0391784 |
OWNER'S MANUAL, Johnson |
| 0391785 |
0391785 |
OWNER'S MANUAL, Johnson |
| 0392355 |
0392355 |
DECAL SET |
| 0392908 |
0392908 |
DECAL SET |
