| Ref | Part Number | Description |
|---|
| 2a |
715900101 |
Fixe Yoke This part replaces 705501372. |
| 2b |
715900129 |
Fixed Joint This part replaces 705501373. |
| 3 |
703500255 |
Rubber Boot Kit |
| 4 |
293650138 |
Oetiker Gear Clamp 44.0MM |
| 5 |
715900326 |
Universal Joint This part replaces 703000022. |
| 6 |
705500841 |
GREASE FITTING - Call your local BRP dealership |
| 7 |
705501123 |
Protector |
| 7a |
705501072 |
SLIDING JOINT - Call your local BRP dealership |
| 8 |
705400036 |
Wear Ring |
| 9 |
Not |
Available As Spare Part - See 08- Rear Differental Ass'y |
| 28 |
705500504 |
Fill Level Plug |
| 29 |
705500506 |
Copper Washer |
| 30 |
705501713 |
LH WHEEL HUB ASSEMBLY - Call your local BRP dealership This part replaces 705501131. |
| 30a |
250300055 |
Wheel Stud M10 X 1.25 This part replaces 250300034. |
| 31 |
705401314 |
Wheel Hub This part replaces 705400713. |
| 32 |
705401964 |
Wheel Stud This part replaces 705400791. |
| 33 |
250000378 |
HEX FLANGED SCREW M12 X 16, SCOTCH GRIP - Call your local BRP dealership |
| 34 |
250200102 |
Flat Washer M12 |
| 35 |
705400552 |
Rubber Bellow This part replaces 705400352. |
| 36 |
705600232 |
Hose Retainer 13 mm |
| 37 |
390406500 |
Pop Rivet 3/16" |
| 38 |
705500893 |
VENT VALVE - Call your local BRP dealership |
| 39 |
293650025 |
Oetiker Gear Clamp |
| 40 |
219704549 |
Hose This part replaces 219704439. |
| 41 |
250001039 |
Hex Flange Screw M12 X 16 This part replaces 250000359. |
| 42 |
293800005 |
Loctite 271, 10 ml |
| 52 |
250200102 |
Flat Washer M12 |
| 53 |
232291413 |
Hex. Flange Castellated Nut M18 This part replaces 250100047. |
| 54 |
250400036 |
Cotter Pin |
| 56 |
293550010 |
Synthetic Grease, 400 G |
| 58 |
705500980 |
CV JOINT - Call your local BRP dealership |
| 60 |
293650204 |
OETIKER CLAMP - Call your local BRP dealership |
| 61 |
293650203 |
Oetiker Clamp (27,5mm) |
| 62 |
705500845 |
CIRCLIP - Call your local BRP dealership |
| 63 |
230602546 |
Hex. Flange Screw M10 X 125 |
| 64 |
233201436 |
Hex. Flange Elastic Nut M10 This part replaces 233201416. |
| 65 |
293350150 |
Ball Bearing This part replaces 293350040. |
| 66 |
705501124 |
Wear Ring |
| 67 |
705501121 |
Wear Sleeve |
| 68 |
293370019 |
Circlip |
