| Ref | Part Number | Description |
|---|
| 5 |
Not |
Available As Spare Part - n/a |
| 56 |
293350150 |
Ball Bearing This part replaces 293350040. |
| 58 |
293370019 |
Circlip |
| 61 |
705501122 |
EXTERNAL WEAR SLEEVE - Call your local BRP dealership This part replaces 705500372. |
| 66 |
250200019 |
WASHER - Call your local BRP dealership |
| 67 |
232291413 |
Hex. Flange Castellated Nut M18 |
| 68 |
250400036 |
Cotter Pin This part replaces 250400016. |
| 71 |
705400012 |
WHEEL CAP - Call your local BRP dealership |
| 72 |
705400213 |
Front Tire |
| 74 |
705400193 |
Rim Valve With Cap |
| 75 |
250100042 |
Steel Wheel Nut |
| 80 |
293550010 |
Synthetic Grease, 400 G |
| 102 |
250000136 |
Socket Head Screw M8 X 20, Scotch Grip |
| 103 |
293300091 |
O-Ring |
