| Ref | Part Number | Description |
|---|
| 3 |
0303212 |
VIS, collier & capot |
| 4 |
0511458 |
COLLIER, fils |
| 5 |
0511459 |
CACHE, fils |
| 6 |
0511460 |
VIS, dispositif de retenue |
| 8 |
0581651 |
STATOR ASSEMBLY |
| 11 |
0511482 |
SLEEVE |
| 12 |
0328426 |
NEEDLE VALVE |
| 13 |
0583696 |
FLYWHEEL ASSEMBLY This part replaces 0582436. |
| 14 |
0329182 |
VIS, borne This part replaces 0327785. |
| 15 |
0582106 |
COIL ASSY |
| 18 |
0395448 |
BALL & SOCKET ASSY This part replaces 0313700. |
| 20 |
0582453 |
POWER PACK |
| 21 |
0511449 |
COMMECTOR, Coil to power pack |
| 25 |
0511563 |
TERMINAL BLOCK |
| 28 |
0314576 |
SCREW |
| 30 |
0313117 |
SCR,Clamp,eng cable |
| 34 |
0582061 |
MOTOR CABLE ASSY |
| 42 |
0310441 |
CLAMP, CPS lead |
| 43 |
0581778 |
REDRESSEUR |
| 45 |
0317000 |
COLLIER, câble |
| 46 |
0332070 |
SCREW, Retaining plate This part replaces 0304442. |
| 47 |
0322549 |
DISPOSITIF DE RETENUE, bouchon |
| 50 |
0582365 |
H.T. LEAD ASSEMBLY, Spark plugs to ignition coil |
| 53 |
0334193 |
RETAINER, Ign. plate assy. This part replaces 0323204. |
| 54 |
0332063 |
PLATE, Support This part replaces 0323398. |
| 57 |
0322435 |
ROULEMENT, plaque d'allumage vers support |
| 64 |
0317753 |
SCREW |
| 67 |
0329816 |
TERINAL |
| 70 |
0313584 |
SPRING |
| 0581855 |
0581855 |
STATOR & ARMATURE PLATE ASSY |
