| Ref | Part Number | Description |
|---|
| 2 |
5031524 |
EXHAUST HOUSING |
| 3 |
*5035792 |
BOLT, (10X45mm) This part replaces *5030399. |
| 4 |
5030511 |
PIN |
| 5 |
5031667 |
LEAD (MOUNT BRKT TO HSG) |
| 6 |
5030886 |
DAMPER, Mount |
| 7 |
5031529 |
MOUNT, LOWER |
| 8 |
5032676 |
BOLT, Lower mount |
| 9 |
5030419 |
NUT |
| 10 |
5030437 |
WASHER |
| 11 |
5030893 |
MOUNT, Lower thrust |
| 12 |
5032677 |
BRACKET, Lower mount |
| 13 |
5031533 |
COVER, Lower mount |
| 14 |
5031217 |
BOLT |
| 15 |
5031221 |
NUT |
| 17 |
5030407 |
SCREW (5X8) |
| 18 |
5030459 |
WASHER |
| 19 |
5032795 |
HOLDER, ENGINE This part replaces 5032242. |
| 21 |
5031673 |
KNOCK PIN |
| 22 |
5031262 |
O RING |
| 23 |
5031266 |
OIL SEAL |
| 24 |
5031527 |
MOUNT, Upper thrust |
| 25 |
5031528 |
MOUNT, Upper |
| 26 |
5032228 |
COVER, Upper mount, stbd |
| 27 |
5032233 |
COVER, Upper mount, port |
| 28 |
5031530 |
STOP, Upper thrust |
| 29 |
5030027 |
BOLT (10X150mm) |
| 30 |
5035665 |
BOLT (8X40) This part replaces 5030393. |
| 31 |
5030394 |
BOLT (8X30mm) |
| 32 |
*5030054 |
NUT |
| 33 |
5031224 |
WASHER |
| 34 |
5030057 |
WASHER |
| 35 |
5031668 |
WASHER |
| 36 |
5031408 |
CASE, Oil pump |
| 42 |
5031412 |
STRAINER, OIL |
| 43 |
5032783 |
GUIDE, OIL LEVEL GAUGE This part replaces 5031414. |
| 44 |
5031212 |
BOLT |
| 47 |
5031262 |
O RING |
| 49 |
5031672 |
BOLT |
| 50 |
5031673 |
KNOCK PIN |
| 51 |
0778885 |
FILTER Assy, Oil This part replaces 5031411. |
| 52 |
5031413 |
GAUGE, Oil level |
| 54 |
5034437 |
PAN, OIL This part replaces 5031308. |
| 55 |
5030929 |
TUBE, WATER INDICATOR |
| 56 |
5030930 |
COVER |
| 58 |
5031210 |
BOLT, STUD |
| 59 |
5031212 |
BOLT |
| 60 |
5031213 |
BOLT (8X95mm) |
| 61 |
5031214 |
BOLT (10X150mm) |
| 62 |
5030057 |
WASHER |
| 63 |
5031219 |
NUT |
| 64 |
5030465 |
GASKET |
| 65 |
5030525 |
PLUG |
| 66 |
5031673 |
KNOCK PIN |
