| Ref | Part Number | Description |
|---|
| 34 |
409010100 |
Female Terminal |
| 36 |
409010400 |
Female Terminal Housing, 1 Circuit |
| 42 |
515175273 |
MALE TERMINAL - Call your local BRP dealership |
| 44 |
515175231 |
Female Terminal |
| 46 |
515175282 |
Female Terminal |
| 54 |
515175495 |
Female Housing, 3 Circuits |
| 88 |
278001009 |
Female Terminal |
| 99 |
278000992 |
Open Barrel |
| 100 |
409012500 |
Open Barrel |
| 101 |
278001392 |
Open Barrel Terminal |
| 110 |
278000631 |
Male Terminal |
| 111 |
515175823 |
Male Terminal |
| 112 |
278000632 |
Female Terminal |
| 113 |
278001661 |
FEMALE TERMINAL - Call your local BRP dealership |
| 114 |
409206900 |
Male Housing, 2 Circuits |
| 119 |
409015800 |
Male Connector, 12 Circuits |
| 120 |
409207300 |
Female Connector, 2 Circuits |
| 122 |
278000739 |
Male Connector, 4 Circuits |
| 126 |
409207500 |
Male Lock, 2 Circuits |
| 127 |
409207600 |
Male Lock, 3 Circuits |
| 129 |
278000735 |
Female Lock, 6 Circuits |
| 131 |
Not |
Available As Spare Part - Male Lock (12 Circuits) |
| 132 |
409207100 |
FEMALE LOCK, 2 CIRCUITS - Call your local BRP dealership |
| 134 |
278000738 |
Male Lock, 4 Circuits |
| 138 |
293000052 |
Sealing Cap |
| 172 |
561503100 |
FEMALE TERMINAL - Call your local BRP dealership |
| 192 |
409003900 |
Fuse, 20 Amperes |
| 193 |
278001197 |
Fuse, 10 Amperes |
| 194 |
278001197 |
Fuse, 10 Amperes |
| 196 |
293750002 |
Tie Wrap 142 mm |
| 202 |
278001114 |
Female Terminal |
| 203 |
278001113 |
Male Connector, 2 Circuits |
| 204 |
409003600 |
Female Terminal |
| 206 |
409004200 |
Female Terminal |
| 224 |
515175321 |
FEMALE TERMINAL - Call your local BRP dealership |
| 225 |
409202700 |
FEMALE TERMINAL HOUSING, 3 CIRCUITS - Call your local BRP dealership |
| 226 |
278000222 |
Male Terminal |
| 228 |
409007300 |
Female Terminal |
| 229 |
278000223 |
Female Terminal |
| 231 |
278000217 |
Female Housing, 2 Circuits |
| 237 |
278000220 |
Male Connector, 2 Circuits |
| 242 |
278000218 |
Wire Seal |
| 243 |
710000048 |
Wire Seal |
| 246 |
409004300 |
Male Terminal |
| 253 |
219704425 |
Tubing 6 Mm 3000Mm Long |
| 254 |
219704399 |
Was 409901700 Tubing (9 mm) |
| 255 |
219704400 |
Was 409901800 Tubing (13 mm) |
| 256 |
219704408 |
Tubing 16 Mm 1000Mm Long |
| 257 |
219704398 |
Was 409901600 Tubing 19mm |
| 258 |
219704407 |
Tubing 10 MM 1000MM Long |
| 260 |
219704423 |
Was 515175319 Tubing 22 mm |
| 280 |
409012100 |
Female Terminal |
| 285 |
710000078 |
HOUSING-TAB - Call your local BRP dealership |
| 286 |
409012300 |
Seal |
| 287 |
710000080 |
Cap |
| 297 |
278001007 |
Insulated Sheath |
| 300 |
278000343 |
Fuse, 15 Amperes |
| 307 |
515175509 |
MALE TERMINAL HOUSING, 1 CIRCUIT - Call your local BRP dealership |
| 308 |
515175510 |
FEMALE TERMINAL HOUSING, 1 CIRCUIT - Call your local BRP dealership |
| 309 |
515175543 |
Female Terminal Housing, 6 Circuits |
| 318 |
278001477 |
FEMALE HOUSING, 4 CIRCUITS - Call your local BRP dealership |
| 319 |
515175568 |
Male Terminal |
| 323 |
515175580 |
Low Temperatue Tubing |
| 341 |
Not |
Available As Spare Part - Tubing Shrink |
| 346 |
278001478 |
MALE WEDGE, 4 CIRCUITS - Call your local BRP dealership |
| 355 |
515175658 |
Female Housing, 2 Circuits |
| 359 |
515175666 |
Male Housing |
| 361 |
515175668 |
Male Terminal Housing, 6 Circuits |
| 365 |
515175672 |
CONNECTOR_MALE 4 CAVITIES - Call your local BRP dealership |
| 366 |
515175673 |
Male Housing, 6 Circuits |
| 370 |
515175677 |
MALE WEDGE, 4 CIRCUITS - Call your local BRP dealership |
| 371 |
515175678 |
Male Wedge, 6 Circuits |
| 382 |
515175704 |
FEMALE TERMINAL HOUSING, 12 CIRCUITS - Call your local BRP dealership |
| 387 |
219704453 |
Was 293550004 Dielectric Grease, 150 g |
| 388 |
278001750 |
FEMALE TERMINAL - Call your local BRP dealership |
| 389 |
278001752 |
Female Terminal |
| 391 |
278001751 |
MALE HOUSING, 41 CIRCUITS - Call your local BRP dealership |
| 401 |
278001505 |
WIRE SEAL - Call your local BRP dealership |
| 409 |
515175812 |
Plug |
| 410 |
515175801 |
Female Housing, 24 Circuits |
| 411 |
515175802 |
Retainer Block |
| 412 |
515175803 |
Wire Seal |
| 413 |
515175804 |
BLOCK - Call your local BRP dealership |
| 414 |
515175805 |
LOCK - Call your local BRP dealership |
| 415 |
515175806 |
Female Terminal |
| 430 |
515175857 |
FUSE HOLDER - Call your local BRP dealership |
| 431 |
515175856 |
RELAY HOLDER - Call your local BRP dealership |
| 433 |
515175854 |
FEMALE TERMINAL - Call your local BRP dealership |
| 437 |
515175886 |
SEAL - Call your local BRP dealership |
| 438 |
515175883 |
Latch |
| 439 |
515175884 |
LOCK - Call your local BRP dealership |
| 440 |
515175885 |
COVER - Call your local BRP dealership |
| 441 |
515177672 |
Relais *Relay This part replaces 410113604. |
| 443 |
710000335 |
Female Terminal |
| 466 |
415128525 |
Fuse, 0.5 Ampere |
| 469 |
414115200 |
Tie-Rap 180 mm |
| 469 |
515175979 |
SEAL - Call your local BRP dealership |
| 490 |
710000394 |
SEAL WIRE - Call your local BRP dealership |
| 491 |
710000395 |
FEMALE HOUSING - Call your local BRP dealership |
| 492 |
710000396 |
Female Housing 32 Pins |
| 501 |
515176065 |
FUSE BOX BASE - Call your local BRP dealership |
| 502 |
710000413 |
HOUSING - Call your local BRP dealership |
| 504 |
278001065 |
Wire Seal |
| 593 |
515176069 |
MALE TERMINAL HOUSING, 3 CIRCUITS - Call your local BRP dealership |
| 597 |
515176055 |
Terminal Retainer |
| 598 |
515176051 |
Female Housing |
| 599 |
515176053 |
FEMALE TERMINAL - Call your local BRP dealership |
| 600 |
515176052 |
FEMALE TERMINAL - Call your local BRP dealership |
| 601 |
515176056 |
Latch |
| 602 |
515176057 |
Lock |
| 603 |
278002704 |
Diagnostic Connector This part replaces 278001725. |
| 604 |
515176054 |
Female Housing |
| 620 |
515176106 |
Female Terminal |
| 624 |
710000221 |
Female Terminal |
| 625 |
278001321 |
MALE TERMINAL HOUSING, 8 CIRCUITS - Call your local BRP dealership |
| 627 |
515176110 |
Wire Seal |
