08- Electric - Upper Section
Parts (32)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 5037262 | LEVER, CLUTCH |
| 2 | 5037263 | KNOB, Clutch lever |
| 3 | 5037264 | BUSHING, Clutch shaft |
| 4 | 5037265 | BUSHING, Clutch shaft no. 2 |
| 5 | 5037266 | ARM, CLUTCH ROD |
| 6 | 5037267 | SPRING, CLUTCH NOTCH |
| 7 | 5037268 | WASHER |
| 8 | 5031249 | PIN |
| 9 | 5037269 | PIN, Clutch lever |
| 10 | 515178226 | Multifunction Gauge Full Size Color |
| 60 | 515178450 | Housing |
| 70 | 250000725 | Screw M4 X 16 |
| 600 | 710006855 | Ignition Switch |
| 610 | 278004274 | Specialized Nut |
| 620 | 515179476 | Grey, LYNX DESS Key |
| 800 | 515178645 | Heated Visor Wiring Harness |
| 810 | 572103300 | Cap |
| 1000 | 219400510 | USB Outlet |
| 1010 | 515178190 | Harness |
| 1040 | 515178153 | Extension Harness |
| 2400 | 515178102 | LH Housing |
| 2410 | 515177147 | Housing Plate |
| 2420 | 250000671 | Torx Screw |
| 2470 | 415130141 | Sleeve |
| 2480 | 415130141 | Sleeve |
| 2600 | 515177931 | Emergency Stop Switch |
| 2610 | 515177310 | Emergency Stop Switch Support |
| 2620 | 250000263 | Torx Screw #8-18 |
| 2996 | 250000911 | Hex. Flange Screw M5 X 16 |
| 3250 | 515178501 | Rocket Switch |
| 5000 | 420464172 | ECM Module |
| 5020 | 512061397 | Module Support |
