| Ref | Part Number | Description |
|---|
| 1 |
0396394 |
INTAKE MANIFOLD ASSEMBLY |
| 3 |
0314956 |
STUD |
| 4 |
0330115 |
CLAMP, Power pack connector |
| 5 |
0329594 |
SCREW, Cam follower |
| 7 |
0392988 |
CHECK VALVE |
| 8 |
0331839 |
BUSHING |
| 9 |
0397036 |
LEVER & PIN |
| 10 |
0389823 |
CLAPET |
| 10 |
503195703 |
Runner |
| 15 |
0320930 |
COVER, Air silencer |
| 16 |
0320575 |
ADJ LEVER, Throttle link |
| 17 |
5007356 |
Kit Ay This part replaces 0582865. |
| 20 |
503196124 |
Slider Shoe |
| 22 |
0511807 |
COVER&GASKET AY |
| 23 |
0333448 |
GASKET This part replaces 0511808. |
| 25 |
0333448 |
GASKET This part replaces 0511810. |
| 30 |
208562531 |
Phillips Screw M6 X 25 |
| 31 |
0330130 |
ROLLER |
| 32 |
0321907 |
GASKET, Leaf plate |
| 33 |
0313329 |
LOCKWASHER, Carburetor link |
| 36 |
0330665 |
THROTTLE AM |
| 37 |
0133451 |
SCREW, Leaf plate manifold, short |
| 38 |
HOSE, |
Air silencer 6-1/2" long |
| 40 |
0306418 |
VIS, ancrage |
| 40 |
232561434 |
Elastic Stop Nut M6 |
| 42 |
0328695 |
CLAMP, Engine cable |
| 44 |
0330118 |
CLAMP |
| 45 |
0319292 |
SCREW, Clamp |
| 46 |
0319771 |
GASKET SET, Air silencer |
| 47 |
0327707 |
GASKET, Air silencer |
| 48 |
0328738 |
LOCKWASHER |
| 49 |
0321183 |
GASKET, Cover |
| 50 |
0432272 |
LINK AND PIN, Throttle arm This part replaces 0394723. |
| 54 |
0328733 |
RONDELLE ÉLASTIQUE, levier de sens de marche |
| 55 |
0314416 |
BUMBER, Advance screw |
| 56 |
0328722 |
SCREW, Spark adjust |
| 60 |
0328742 |
NUT |
| 60 |
503195286 |
Front Wheel Shaft |
| 61 |
0391254 |
BASE, Air silencer |
| 62 |
0325388 |
RETAINER, Air silencer base |
| 65 |
HOSE, |
Primer solenoid system |
| 66 |
0330151 |
CLAMP, Harness to oil tank boss This part replaces 0316386. |
| 67 |
0325569 |
T, amorçage |
| 68 |
0313217 |
SCREW |
| 69 |
0325564 |
CONNECTOR, Drain hose |
| 70 |
0329182 |
VIS, borne |
| 70a |
503190396 |
Ball Bearing |
| 70b |
415129371 |
Retaining Ring |
| 80 |
205504544 |
Socket Screw |
| 90 |
234001410 |
Flat Washer 10 mm |
| 200 |
503193504 |
Rubber Stopper |
| 210 |
293150224 |
Rivet Pop 3/16 |
| 220 |
503191273 |
Washer |
| 230 |
503195028 |
Rubber Stopper |
| 240 |
293150224 |
Rivet Pop 3/16 |
| 250 |
503191273 |
Washer |
| 260 |
503191291 |
Rubber Stopper |
| 270 |
293150224 |
Rivet Pop 3/16 |
| 280 |
503191273 |
Washer |
| 310a |
503190396 |
Ball Bearing |
| 310b |
415129371 |
Retaining Ring |
| 320a |
503190396 |
Ball Bearing |
| 320b |
415129371 |
Retaining Ring |
| 330 |
503193894 |
Casted Support |
| 340 |
250000944 |
Hex. Flange Screw M6 X 70 |
| 345 |
207068044 |
Screw Hex. M6 X 80 |
| 350 |
503191820 |
Wheel Cup M6 |
| 360 |
233261466 |
Hex. Flanged Elastic Nut M6 |
| 370 |
250000945 |
Hex. Flange Screw M6 X 25 |
| 390 |
503195345 |
Black, Wheel Cap |
| 400 |
503195345 |
Black, Wheel Cap |
| 2430 |
503195233 |
Center Shock Shaft |
| 2440 |
503195044 |
Spacer |
| 2445 |
503195044 |
Spacer |
| 2450 |
503189276 |
Washer |
| 2460 |
205523554 |
Socket Head Screw M12 X 35 |
| 2500 |
503195022 |
LH Rail Pivot Ass'y |
| 2505 |
503195023 |
RH Rail Pivot Ass'y |
| 2510 |
503194971 |
Pivot Spring |
| 2520 |
503194763 |
Ball Joint Link |
| 2530 |
503192491 |
Washer |
| 2550 |
233281464 |
Elastic Flange Nut M8 |
| 2560 |
207683544 |
Hex. Flange Screw M8 X 35 |
| 2570 |
232581414 |
Hex. Elastic Stop Nut M8 |
| 2580 |
503196408 |
Extension Spring Support |
| 2590 |
207662556 |
Hex. Flange Screw M6 X 25 |
| 2600 |
233261466 |
Hex. Flanged Elastic Nut M6 |
| 2610 |
503195064 |
Tensioner |
| 2620 |
250000983 |
Hex. Cap Screw With Nylon Patch |
| 2630 |
250200111 |
Washer |
| 2660 |
503194912 |
Lower Shaft |
| 2670 |
503192491 |
Washer |
| 2680 |
250000537 |
Hex. Cap Screw M12 X 35 |
| 2690 |
706200281 |
Hardened Washer |
| 2800 |
503190429 |
Rear Axle |
| 2820 |
503195057 |
Spacer |
| 2830 |
503194647 |
Spacer |
| 2840a |
503190396 |
Ball Bearing |
| 2840b |
415129371 |
Retaining Ring |
| 2850 |
31013 |
Shim Ring |
| 2870a |
503190396 |
Ball Bearing |
| 2870b |
415129371 |
Retaining Ring |
| 2880 |
503190439 |
Washer |
| 2890 |
250000817 |
Hex Screw With Nilon Patch, M10 X 35 |
