08- Electric - Upper Section
Parts (31)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 5008623 | FUEL TANK This part replaces 0381015. |
| 2 | 0304888 | SCREW |
| 4 | 0310849 | HOUSING ASSY., Valve |
| 5 | 0312191 | SCREW, Indicator support |
| 6 | 0312190 | LENS |
| 7 | 0332505 | SEAL This part replaces 0312192. |
| 9 | 0398459 | FLOAT & INDICATOR This part replaces 0310845. |
| 10 | 0312193 | GASKET |
| 10 | 515178226 | Multifunction Gauge Full Size Color |
| 12 | 0125530 | GASKET, Housing to tank This part replaces 0310984. |
| 13 | 0377536 | FEUL TANK CAP ASSY |
| 16 | 0398409 | HOUSING This part replaces 0381016. |
| 20 | 0332488 | RING, Quad This part replaces 0307858. |
| 29 | 0306801 | CLAMP, Hose, small |
| 60 | 515178450 | Housing |
| 70 | 250000725 | Screw M4 X 16 |
| 600 | 515179240 | Terminal Dess One Wire |
| 610 | 278004274 | Specialized Nut |
| 620 | 515179476 | Grey, LYNX DESS Key |
| 800 | 515178645 | Heated Visor Wiring Harness |
| 810 | 572103300 | Cap |
| 1000 | 219400510 | USB Outlet |
| 1010 | 515178190 | Harness |
| 1040 | 515178153 | Extension Harness |
| 2400 | 515178102 | LH Housing |
| 2410 | 515177147 | Housing Plate |
| 2420 | 250000671 | Torx Screw |
| 2470 | 415130141 | Sleeve |
| 3010 | 515177929 | Rivet |
| 3211 | 515178202 | Connector Coil |
| 0386940 | 5008609 | FLEXIBLE DE CARBURANT ET POIRE D'AMORÇAGE This part replaces 0386940. |
