| Ref | Part Number | Description |
|---|
| 10 |
415131058 |
Deep Black, Chassis Tunnel Module 154 |
| 10a11 |
518337274 |
Front Suspension Arm Reinforcement This part replaces 518336141. |
| 10a12 |
518337124 |
LH Rear Suspension Support |
| 10a13 |
518337125 |
RH Rear Suspension Support |
| 10a16 |
518329789 |
RH Footrest Reinforcement |
| 10a17 |
518332924 |
Deep Black, LH Chassis Reinforcement |
| 10a18 |
518329648 |
RH Roller |
| 10a19 |
518328452 |
LH Roller |
| 10a20 |
518336064 |
RH Footrest Reinforcement |
| 10a21 |
518336063 |
LH Footrest Reinforcement |
| 10a23 |
518336024 |
Radiator Tunnel 154 |
| 10a24 |
250300652 |
Protruding Stud M8 x 22 |
| 10a25 |
605636003 |
Clinch Nut M6 Hexsert |
| 10a26 |
293450369 |
Threaded Insert M6 X 1.0 |
| 10a27 |
293450275 |
Insert |
| 10a29 |
250001151 |
Torx Button Head Screw M8 X 25 |
| 10a2b |
250300027 |
Clinch Stud M6 X 20 |
| 10a3 |
518332803 |
Deep Black, RH Footrest Reinforcement |
| 10a30 |
518331822 |
RH Footrest |
| 10a31 |
518332977 |
LH Footrest |
| 10a36 |
390909100 |
Avex Rivet |
| 10a37 |
390909200 |
Avex Rivet |
| 10a43 |
293150264 |
Rivet Ornit 6,5 X 10.5 |
| 10a44 |
293150265 |
Rivet Ornit 6,5 X 12.5 |
| 10a45 |
293150266 |
Ornit Rivet 6,5 X 14.5 |
| 10a47 |
293150267 |
Rivet Ornit 6,5 X 16.5 |
| 10a48 |
293150154 |
Magna-Grip Rivet 6.4 X 65,9 |
| 10a49 |
293150149 |
Collar Huck Magna-Grip 6.4 |
| 10a6 |
518332802 |
Deep Black, LH Footrest Reinforcement |
| 10a7 |
518331712 |
LH Frame Corner 24 |
| 10a8 |
518331973 |
RH Frame Corner 24 |
| 20 |
293730052 |
Black, Plug |
| 35 |
518331727 |
RH Stirrup Reinforcement |
| 40 |
293450275 |
Insert |
| 42 |
250000717 |
Torx Head Screw M6 X 16 |
| 50 |
518331823 |
Heat Shield |
| 55 |
293450275 |
Insert |
| 60 |
250000717 |
Torx Head Screw M6 X 16 |
| 170 |
293450267 |
Insert M5 - 0.8 |
| 200 |
518332541 |
Lateral Reinforcement |
| 205 |
207682044 |
Hex. Flange Screw M8 X 20 |
| 210 |
232081414 |
Hex. Nut M8 |
| 230 |
207562056 |
Hex. Flange Screw M6 X 20 |
| 425 |
207562056 |
Hex. Flange Screw M6 X 20 |
| 430 |
233261416 |
Elastic Flange Nut M6 X 1.0 |
| 860 |
518335168 |
Deep Black, LH Rear Footrest Reinforcement |
| 865 |
518335169 |
Deep Black, RH Rear Footrest Reinforcement |
| 875 |
293150267 |
Rivet Ornit 6,5 X 16.5 |
| 880 |
293150148 |
Rivet Magna-Grip 6,4 X 50,8 |
| 885 |
293150149 |
Collar Huck Magna-Grip 6.4 |
| 1160 |
293150266 |
Ornit Rivet 6,5 X 14.5 |
| 1170 |
518334031 |
Muffler Support Ass'y |
| 1700 |
518329982 |
Front Protector |
| 1710 |
293150308 |
Black, Ornit Rivet 3/16 X ,675 This part replaces 293150308. |
