| Ref | Part Number | Description |
|---|
| 1 |
0586526 |
FLYWHEEL Assy |
| 2 |
0336135 |
SCREW, Flywheel |
| 4 |
5004519 |
COVER Assy, Flywheel This part replaces 0439751. |
| 6 |
0343525 |
SCREW, Stator |
| 10 |
0360252 |
WASHER This part replaces 0306311. |
| 12 |
0331036 |
VIS, attache de palier |
| 14 |
0514891 |
CLAMP, Capacitor |
| 15 |
0909533 |
SCREW, Pressure relief valve cover |
| 17 |
0347194 |
HOSE, EMM drain |
| 19 |
0909676 |
SCREW |
| 20 |
0343468 |
COVER, Sensor |
| 31 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 33 |
0586333 |
COIL ASSY., Single |
| 34 |
0583740 |
COIL Assy |
| 39 |
0586523 |
SENSOR Assy, Crank position |
| 43 |
5001891 |
LEAD ASSY., Ignition coil |
| 45 |
0350357 |
GASKET, BASE PLATE This part replaces 0342291. |
| 50 |
0336316 |
WASHER, screw, bracket to hood |
| 57 |
5000870 |
COIL BRACKET |
| 58 |
0514867 |
BRACKET, Fuse assy. |
| 59 |
0343598 |
BUMPER, Bracket to block |
| 67 |
0586754 |
POWER DISTRIBUTION PANEL This part replaces 0586379. |
| 74 |
3010815 |
BASE PLATE |
| 75 |
0346547 |
BOLT, Double-ended |
| 76 |
0346538 |
BRACKET, Capacitor mounting |
| 81 |
0328695 |
CLAMP, Engine cable |
| 82 |
0329110 |
VIS, boîtier d'échappement vers bloc cylindres-carter This part replaces 0319358. |
| 83 |
0586546 |
FILTER Assy |
| 89 |
0586514 |
STATOR Assy |
