| Ref | Part Number | Description |
|---|
| 0173029 |
0173029 |
ANODE |
| 0306014 |
0306014 |
VIS, ancrage |
| 0306423 |
0306423 |
BOLT |
| 0307238 |
0307238 |
RONDELLE |
| 0313327 |
0363012 |
SCREW, Bracket mounting This part replaces 0313327. |
| 0313580 |
0313580 |
WASHER |
| 0313581 |
0313581 |
BUMBER, Mount screw |
| 0313623 |
0363254 |
NUT, Stern bracket screw This part replaces 0313623. |
| 0314390 |
0314390 |
RETAINER |
| 0315081 |
0315081 |
BAGUE, arbre de commande de sens de marche vers bloc-cylindres |
| 0317782 |
0317782 |
THRUST WASHER |
| 0317894 |
0317894 |
CACHE, tube de relevage |
| 0318238 |
0318238 |
SCREW |
| 0318272 |
0318272 |
Nut backing plate (square) 1/2 in. |
| 0318273 |
0318273 |
Bolt hex retainer 1/2 in. |
| 0318572 |
0318572 |
Bolt thread protective cap 1/2 in. |
| 0318573 |
0318573 |
SCREW, Bracket mount, 3 1/2 in. (12.7 x 89mm) |
| 0319787 |
0319787 |
BUSHING |
| 0319886 |
0319886 |
SCREW |
| 0320248 |
0320248 |
RONDELLE, écrou |
| 0321232 |
0321232 |
RETAINER WASHER |
| 0321511 |
0351896 |
TILT TUBE This part replaces 0321511. |
| 0321577 |
0363011 |
SCREW, Stern bracket mounting, 1/2 x 5.75 in. (146 mm) This part replaces 0321577. |
| 0323599 |
0323599 |
LOCKNUT |
| 0324952 |
0324952 |
CLAMP |
| 0328260 |
0328260 |
E-RING |
| 0332435 |
0332435 |
PIN |
| 0332440 |
0350642 |
SWIVEL BRACKET This part replaces 0332440. |
| 0332441 |
0344332 |
SEAL, Steering arm This part replaces 0332441. |
| 0332447 |
0332447 |
PIN,TILT |
| 0332452 |
0332452 |
SEAL, Upper |
| 0332453 |
0332453 |
THRUST WASHER |
| 0333622 |
0344104 |
STERN BRACKET, Port This part replaces 0333622. |
| 0333674 |
0333674 |
SCREW, Anode |
| 0333765 |
0333765 |
SPRING |
| 0333821 |
0333821 |
WASHER |
| 0333868 |
0333868 |
SCREW |
| 0334161 |
0334161 |
ANCHOR BLOCK |
| 0334162 |
0334162 |
WASHER |
| 0334247 |
0357240 |
TIE BAR, Stern bracket This part replaces 0334247. |
| 0334259 |
0334259 |
CLIP |
| 0334337 |
0334337 |
BUSHING |
| 0334438 |
0334438 |
KNOB |
| 0387043 |
0582494 |
GROUND STRAP This part replaces 0387043. |
| 0388234 |
0436470 |
MOUNT, Upper This part replaces 0388234. |
| 0397531 |
0433585 |
ARM & SHAFT Assy This part replaces 0397531. |
| 0398752 |
0434037 |
TILT ASSIST CYLINDER This part replaces 0398752. |
| 0398875 |
0398875 |
LEVER & SHAFT |
| 0431962 |
0431962 |
LEVER Assy, Tilt assist |
| 0432024 |
0436202 |
CABLE, Tilt assist This part replaces 0432024. |
| 0432293 |
0432293 |
LEVER Assembly, Trail lock |
