| Ref | Part Number | Description |
|---|
| 17 |
0305123 |
O RING |
| 26 |
0434467 |
NEEDLE BEARING ASSY. |
| 36 |
0335510 |
SHIFT ROD |
| 37 |
5004590 |
Gearset Ay This part replaces 0434064. |
| 43 |
0314361 |
SHIM, 0.004 |
| 53 |
5000624 |
DRIVESHAFT Assembly, Upper This part replaces 0338023. |
| 55 |
0335684 |
DRIVESHAFT SPRING |
| 60 |
0338743 |
TRIM TAB This part replaces 0333961. |
| 63 |
0435027 |
CUP & PLATE This part replaces 0330379. |
| 63 |
0435526 |
CHROME CUP & PLATE KIT This part replaces 0330384. |
| 65 |
0313715 |
SCREW, Cap, hex hd, 7/16-14 x 1 |
| 66 |
0435027 |
CUP & PLATE This part replaces 0330380. |
| 66 |
0435526 |
CHROME CUP & PLATE KIT This part replaces 0330383. |
| 69 |
0332065 |
SEAL, Engine cover, stbd. |
| 70 |
0331998 |
SCREW, Gearcase to housing |
| 72 |
0331999 |
SCREW, Gearcase housing |
| 73 |
0331353 |
Seal, Impeller Housing Plate. |
| 80 |
0330263 |
SCREW, Mounting, 3/8 in. X 3.50 in. |
| 81 |
0332000 |
SEAL RING |
| 82 |
0335221 |
SCREW, Throttle body to reed plate This part replaces 0328715. |
| 84 |
0435485 |
IMPELLER HOUSING ASSY. This part replaces 0395040. |
| 85 |
PROPELLER |
Ref: 86 0313926 *Propeller Hub Sleeve 0313926 |
| 88 |
5006373 |
GEARCASE SEAL KIT This part replaces 0434516. |
| 89 |
5001594 |
WATER PUMP REPAIR KIT This part replaces 0395060. |
| 0435194 |
0435194 |
GEARCASE., Complete |
