| Ref | Part Number | Description |
|---|
| NS |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 1 |
0353592 |
SCREW, Cam to intake |
| 3 |
5006475 |
THROTTLE CAM |
| 4 |
0908398 |
WASHER |
| 5 |
5006478 |
LINK, Cam to shaft-TPS |
| 6 |
0353592 |
SCREW, Cam to intake |
| 7 |
0127386 |
RONDELLE |
| 8 |
0324678 |
JOINT TORIQUE Galet de came de papillon |
| 9 |
0432639 |
GALET, contre-came |
| 10 |
5005187 |
THROTTLE LEVER |
| 11 |
0353036 |
SPRING, Throttle lever return |
| 12 |
0908398 |
WASHER |
| 15 |
0353897 |
VIS, dispositif de blocage vers levier de sens de marche |
| 17 |
0360630 |
NUT, M6 This part replaces 0353694. |
| 18 |
5007059 |
LEVER & PIN ASSEMBLY, Shift shaft |
| 19 |
0353968 |
DETENT, Shift lever |
| 20 |
0315164 |
BALL, Shift detent |
| 21 |
0334241 |
GUIDE |
| 22 |
0334338 |
SCREW, Lever to shift rod |
| 23 |
0315081 |
BAGUE, arbre de commande de sens de marche vers bloc-cylindres |
| 24 |
0353804 |
SPACER, Shift lever to block |
| 25 |
5007060 |
LEVER & SHAFT Assembly, Shift |
| 26 |
0353706 |
SHIFT ROD - 20 inch |
| 28 |
0338630 |
BRIDE, à ressort, tige de commande de sens de marche vers levier coudé |
| 29 |
0586780 |
INTERRUPTEUR, de sécurité au point mort |
| 37 |
0351928 |
CLAMP, Trunnion cable |
| 39 |
0358348 |
GUARD, Throttle cam |
| 150 |
514053487 |
Exhaust Gasket |
| 160 |
514055512 |
Support |
| 170 |
515176795 |
Tie Rap Mount (Screwable) |
| 180 |
390909100 |
Avex Rivet |
| 190 |
514055537 |
Washer 3/16 |
| 200b |
514056281 |
Shell |
| 200c |
514056282 |
Shell |
| 200d |
514056421 |
Rear Upper Shell This part replaces 514055617. |
| 200f |
514056141 |
Rear Lower Aluminum Shell |
| 200g |
514056351 |
Glass Wool |
| 200h |
514056352 |
Glass Wool |
| 200j |
514055844 |
Plate |
| 200k |
390909200 |
Avex Rivet |
| 200m |
390909200 |
Avex Rivet |
| 200n |
514055632 |
Rubber |
| 200p |
514055537 |
Washer 3/16 |
| 250 |
514055965 |
Seal |
| 300 |
514055294 |
Exhaust Gasket |
| 310 |
293150266 |
Rivet Ornit 6,5 X 14.5 |
| 320 |
514055214 |
Support |
| 350 |
514055283 |
Front Shield |
| 360 |
514055284 |
Rear Shield |
| 370 |
514056382 |
Wool Glass Tail This part replaces 514056209. |
| 380 |
514056035 |
Clip |
| 400b |
514055980 |
RH Deflector |
| 400c |
514056315 |
LH Deflector |
| 400d |
514056353 |
Glass Wool |
| 400f |
514056354 |
Glass Wool |
| 400g |
514056193 |
Exhaust Support |
| 400h |
514056082 |
Exhaust Support |
| 400j |
514056083 |
Exhaust Support |
| 400k |
390402200 |
Pop Rivet 3/16 |
| 400m |
514055203 |
Stopper |
| 400n |
514056138 |
Stopper Ass'y |
| 420 |
514055282 |
Spring |
| 430 |
250000926 |
Hex. Flanged Screw M6 |
| 500 |
514055198 |
Spring |
| 700 |
514056266 |
Exhaust Temperature Sensor |
| 710 |
515178170 |
Module |
