| Ref | Part Number | Description |
|---|
| 1 |
0387839 |
LEVER & PIN ASSY |
| 3 |
0314906 |
CLIP |
| 5 |
0318073 |
PLUG, Idle restriction, 140 |
| 6 |
0322936 |
ORIFICE, # 28 |
| 8 |
0390636 |
FLOAT CHAMBER ASSY |
| 10 |
0338884 |
GASKET, Float bowl This part replaces 0323784. |
| 11 |
0307466 |
SCRES, Bowl to body |
| 20 |
0321728 |
LEVER AND HANDLE |
| 21 |
0307832 |
PLUG, Screw |
| 22 |
0310540 |
RONDELLE, arbre de verrouillage de relevage, extérieur |
| 27 |
0317501 |
SCREW PLUG, Orifice |
| 30 |
0383437 |
FLOAT ASSEMBLY |
| 32 |
0317646 |
ORIFICE PLUG (54C) |
| 32 |
0322810 |
ORIFACEPLUG |
| 32 |
0323903 |
ORIFICE PLUG, (48c), 85 |
| 32 |
0324906 |
ORFICE PLUG, (50c), 100 |
| 33 |
0316291 |
NUT |
| 34 |
0315052 |
GASKET CARB. TO MANIFOLD |
| 0388862 |
0388862 |
CARB ASSY. , Upper , 115 HP |
| 0388863 |
0388863 |
CARB ASSY., Lower ,115 HP |
| 0389348 |
0389348 |
CARB ASSY., Upper, 85 |
| 0389349 |
0389349 |
CARB ASSY., Lower, 85 |
| 0389784 |
0389784 |
CABR ASSY., Lower, 140 |
| 0389785 |
0389785 |
CARB ASSY. , Upper 140 HP |
| 0389988 |
0389988 |
CARB ASSY., Lower 100 |
| 0389989 |
0389989 |
CARB ASSY., Upper 100 |
