| Ref | Part Number | Description |
|---|
| 1 |
0172922 |
GAUGE ASSY, Trim indicator, black bezel |
| 10a |
861805514 |
Plate Kit Ass'y |
| 10b |
233261434 |
Flanged Elastic Nut M6 |
| 15 |
0319809 |
THRUST ROD |
| 16 |
0581718 |
CABLE ASSY. |
| 24 |
0310755 |
LOCKWASHER, Solenoid term |
| 25 |
0122612 |
LIFT BRACKET |
| 26 |
0322624 |
WASHER, Lag screw This part replaces 0313169. |
| 30 |
233261434 |
Flanged Elastic Nut M6 |
| 32 |
0174520 |
O-RING KIT This part replaces 0172575. |
| 43 |
0174520 |
O-RING KIT This part replaces 0172575. |
| 60 |
504082900 |
Washer |
| 62 |
0341013 |
SCREW, Cover This part replaces 0908668. |
| 65 |
0122619 |
CONNECTOR |
| 66 |
0172577 |
PUMP ASSY |
| 67 |
0172849 |
BOLT KIT |
| 68 |
0172579 |
BRUSH HOLDER ASSY |
| 69 |
0172580 |
CIRCUIT BREAKER ASSEMBLY |
| 70 |
0172717 |
GASKET & "O" RING KIT |
| 70 |
250000740 |
Torx Screw M8 X 20, Scotch Grip |
| 71 |
0122748 |
GASKET, Motor reservoir |
| 72 |
0172845 |
END CAP & BEARING ASSY. |
| 73 |
0172848 |
RESERVOIR |
| 74 |
0122620 |
MOTOR SHELL |
| 75 |
0172576 |
FIELD ASSY |
| 76 |
0172846 |
PLUG KIT |
| 77 |
0172716 |
ARMATURE ASSY |
| 78 |
0122656 |
SPACER |
| 79 |
0172767 |
RELEASE VALVE PKG |
| 80 |
0172768 |
CHECK VALVE & "O" RING ASSEMBLY |
| 80 |
233261434 |
Flanged Elastic Nut M6 |
| 81 |
0172718 |
CABLE ASSY |
| 84 |
0122619 |
CONNECTOR This part replaces 0122789. |
| 100 |
0307708 |
RONDELLE GROWER |
| 100 |
293200168 |
Oil Seal |
| 101 |
0307708 |
RONDELLE GROWER |
| 102 |
0904871 |
SCREW, Solenoid mtg |
| 106 |
0172765 |
LEAD ASSY. |
| 107 |
0203523 |
RING TERMINAL |
| 109 |
0305282 |
BOLT, Bowl & suction piece This part replaces 0301218. |
| 110 |
0319751 |
WASHER, Stern brkt, screw, lower |
| 110 |
293350153 |
Ball Bearing |
| 112 |
0363012 |
SCREW, Bracket mounting This part replaces 0313327. |
| 117 |
0552898 |
SCR,Grc to hsg,short |
| 118 |
0122680 |
PIOVT SCREW,Lift bracket |
| 120 |
504152576 |
Circlip |
| 130 |
504152628 |
Shim |
| 140 |
504153911 |
Sprocket 23 Teeth |
| 280 |
504152784 |
Spring Washer M10 |
| 290 |
207503046 |
Hex. Flange Screw M10 X 30, Scotch Grip |
| 1100 |
293200159 |
Oil Seal |
| 1110 |
293350059 |
Ball Bearing |
| 1120 |
504152582 |
Circlip |
| 1130 |
504153952 |
Sprocket , 51 Teeths |
| 1140 |
293370134 |
Circlip |
| 1150 |
293300201 |
O-Ring |
| 1160b |
504154043 |
Cap |
| 1500 |
504153266 |
Drive Chain (110 Links) |
| 1510 |
414575600 |
Hair Pin |
| 1520 |
504153760 |
Adjustment Screw |
| 1540 |
250500013 |
Hex. Countersunk Drain Plug |
| 1545 |
504153704 |
Magnetic Plug |
| 1550 |
293300202 |
O-Ring |
| 1600 |
504154578 |
Chain Tensioner |
| 1610 |
504153312 |
Chain Slider |
| 1650 |
293370105 |
Circlip |
| 1690 |
250000764 |
Hex. Button Head Screw M8 X 1.25 X 35 |
| 1700d |
515178223 |
Clip Connector |
| 1700f |
415130141 |
Sleeve |
| 1710 |
293300214 |
O Ring |
| 1720 |
250001153 |
Flanged Hex. Screw M6X20 |
| 1740a |
504152930 |
Cap This part replaces 504154304. |
| 1740b |
293710180 |
Straight Pipe Fitting |
| 2000 |
250000717 |
Torx Head Screw M6 X 16 |
| 2030 |
293300201 |
O-Ring |
| 2040 |
504154043 |
Cap |
| 2050 |
504152572 |
Circlip |
| 2500b |
250300028 |
Clinch Stud, M8 X 25 |
| 2510 |
233281414 |
Hex. Flange Elastic Nut M8 |
| 2520 |
293350153 |
Ball Bearing |
| 2550 |
504154153 |
Countershaft |
| 3000 |
504153943 |
Axle Drive Ass'y |
| 3200a |
415129528 |
Track Guide |
| 3200b |
504152651 |
Cleat |
| 4000 |
250000764 |
Hex. Button Head Screw M8 X 1.25 X 35 |
| 0172835 |
0172835 |
HYDRAULIC LIFT ASSY |
| 0581719 |
0581719 |
SOLENOID & CABLE ASSY. |
