| Ref | Part Number | Description |
|---|
| 30 |
207505544 |
Hex. Flange Screw M10 X 55, Scotch Grip |
| 60 |
233201436 |
Hex. Flange Elastic Nut M10 |
| 70 |
250000917 |
Hex. Flange Screw M6 X 20 |
| 80 |
250100198 |
Panel Nut M6 X 1.0 |
| 100 |
207561244 |
Hex. Flange Screw M6 X 12, Scotch Grip |
| 220 |
250200160 |
Flate Washer M8, Aluminum |
| 230 |
211000127 |
Socket Head Screw M8 X 10, Scotch Grip |
| 235 |
205582060 |
Socket Head Screw M8 X 20, Scotch Grip |
| 240 |
707001628 |
Wire Cover |
| 260 |
250000746 |
Torx Truss Screw M8 X 16 |
| 390 |
250000507 |
Hex. Flange Screw M10 X 220 |
| 400 |
707003044 |
Vibration Damper |
| 425 |
293150301 |
Pop Rivet 3/16 X ,551 |
| 427 |
233081436 |
Hex. Flange Nut |
| 430 |
207782046 |
Carriage Bolt M8 X 20 |
| 435 |
233081436 |
Hex. Flange Nut |
| 460 |
207502044 |
Hex Flange Screw M10 X 20 |
| 490 |
207662044 |
Hex. Flange Screw M6 X 20 |
| 500 |
233261466 |
Hex. Flange Elastic Nut M6 |
| 570 |
207682046 |
Hex. Flange Screw M8 X 20 |
| 580 |
233081436 |
Hex. Flange Nut |
| 630 |
707001736 |
Spacer |
| 640 |
707001918 |
Connecting Rod |
| 650 |
207504546 |
Hex. Flange Screw M10 X 45 Scotch Grip |
| 655 |
250001099 |
Hex. Flange Screw M10 X 100 |
| 660 |
233201436 |
Hex. Flange Elastic Nut M10 |
| 760 |
707001627 |
Connector Suppor |
| 770 |
250100208 |
Panel Nut M6 X 1.0 |
| 780 |
207561644 |
Hex. Flange Screw M6 X 16, Scotch Grip |
| 850 |
707601057 |
Upper Heat Deflector |
| 860 |
207561644 |
Hex. Flange Screw M6 X 16, Scotch Grip |
| 870 |
250100198 |
Panel Nut M6 X 1.0 |
| 900 |
250000917 |
Hex. Flange Screw M6 X 20 |
| 910 |
234062600 |
Flat Washer M6, Stainless |
| 1000 |
707001930 |
Skid Plate |
| 1010 |
207561644 |
Hex. Flange Screw M6 X 16, Scotch Grip |
| 1020 |
235381646 |
Torx Screw M8 X 16, Scotch Grip |
| 1030 |
707003260 |
Acoustic Insulation |
