| Ref | Part Number | Description |
|---|
| 1 |
ROPE,Starter |
Ref: 2 0207555 HANDLE 0207555 |
| 3 |
0389713 |
ANCHOR, Rope to handle This part replaces 0320430. |
| 4 |
0318939 |
STARTER PULLEY, Lower |
| 5 |
0318940 |
PINION, Rewind starter |
| 6 |
0318938 |
STARTER PULLER, Upper |
| 7 |
0318944 |
SPRING , Rewind starter |
| 8 |
0318943 |
SPRING, Pinion |
| 9 |
0386113 |
CUP AND GUIDE ASSY |
| 10 |
0318936 |
SCREW, Starter to manifold |
| 1000 |
512061220 |
Rear PTO Support |
| 1020 |
250000986 |
Hex. Flanged Screw M8 X 35 |
| 1030 |
250200146 |
Conical Spring Washer M8 |
| 1200 |
512061193 |
Front PTO Support |
| 1210 |
250000986 |
Hex. Flanged Screw M8 X 35 |
| 1220 |
250200146 |
Conical Spring Washer M8 |
| 1300c |
250000767 |
Torx Truss Screw M6 X 12 |
| 1310 |
250001057 |
Hex. Flanged Screw M8 X 40 Scotch.GRIP |
| 1320 |
250200146 |
Conical Spring Washer M8 |
| 1400 |
512061194 |
Rear Support, Mag |
| 1410 |
250001057 |
Hex. Flanged Screw M8 X 40 Scotch.GRIP |
| 1420 |
250200146 |
Conical Spring Washer M8 |
| 1500 |
512061514 |
Rubber Mount |
| 1540 |
250001062 |
Hex. Flanged Screw M6 X 16 |
| 1550 |
207586044 |
Hex. Flange Screw M8 X 60, Scotch Grip |
| 1560 |
503183200 |
Yellow, Washer |
| 1570 |
250200008 |
Flat Washer With Teflon 8 mm |
| 1575 |
293300123 |
O Ring |
| 1580 |
205082544 |
Socket Screw M6 X 20, Scotch Grip |
| 1595 |
232581414 |
Hex. Elastic Stop Nut M8 |
| 1700 |
512061536 |
Engine Stopper This part replaces 512060826. |
| 1710 |
512060285 |
Spacer |
| 1900 |
250000720 |
Torx Screw K50 X 16 |
| 1930 |
512061327 |
Support Solenoid |
| 3600 |
512061396 |
Throttle Cable |
| 3680 |
414274500 |
Circlip |
| 3690 |
414274500 |
Circlip |
| 3710g |
250000671 |
Torx Screw |
| 3710m |
512060961 |
Screw |
| 3710n |
250001059 |
Torx Truss Head Screw W Nylon M5X14 |
| 3720 |
250000742 |
Torx Screw M5 X 14 |
| 3730a |
414440800 |
Socket Set Screw M8 X 10 |
| 3740 |
512060860 |
Lower Housing |
| 3750 |
512061266 |
Throttle Ass'y |
| 3760 |
250000991 |
Flanged Screw M5x12 |
