07- Front Drive - Common Parts
Parts (37)
| Ref | Part Number | Description |
|---|---|---|
| 10 | 705402066 | Axle Drive Ass'y |
| 10a | 715900435 | U-Joint Cross Kit |
| 10b | 715900497 | Fixed Yoke Joint |
| 10c | 715900231 | Yoke Joint |
| 10d | 703500815 | Grease Fitting |
| 10e | 715900483 | Cover |
| 35 | 705500504 | Fill Level Plug |
| 36 | 705500506 | Copper Washer |
| 40 | 705401872 | RH Front - Premium CV Axle |
| 40a | 715900431 | RH Plunging Joint |
| 40b | 715900427 | CV Joint |
| 40e | 715900282 | Oetiker Clamp |
| 40f | 715900283 | Oetiker Clamp, Small |
| 40h | 715900284 | Oetiker Clamp, Large |
| 40i | 715900261 | Oetiker Clamp, Small |
| 45 | 705401548 | LH Front Knuckle |
| 46 | 705401549 | RH Front Knuckle |
| 50 | 705401871 | LH Front - Premium CV Axle |
| 50a | 715900430 | LH Plunging Joint |
| 50b | 715900427 | CV Joint |
| 50e | 715900282 | Oetiker Clamp |
| 50f | 715900283 | Oetiker Clamp, Small |
| 50h | 715900284 | Oetiker Clamp, Large |
| 50i | 715900261 | Oetiker Clamp, Small |
| 55 | 705400780 | Wear Sleeve |
| 60 | 293350150 | Ball Bearing This part replaces 293350118. |
| 80 | 293370019 | Circlip |
| 90 | 207582044 | Hex. Flange Screw M8 X 20, Scotch Grip |
| 100 | 230602546 | Hex. Flange Screw M10 X 125 |
| 110 | 233201436 | Hex. Flange Elastic Nut M10 This part replaces 233201416. |
| 130 | 705501900 | Wheel Hub |
| 140 | 250300060 | Wheel Stud |
| 150 | 250200171 | Conical Spring Washer M18 |
| 160 | 232291413 | Hex. Flange Castellated Nut M18 |
| 170 | 250400071 | Cotter Pin |
| 180a | 219704389 | Polyurethane Hose 4000MM Long |
| 310 | 250200014 | Flat Washer M10 |
