| Ref | Part Number | Description |
|---|
| 1 |
0121212 |
GASKET |
| 2 |
0171651 |
LEAD |
| 3 |
0171652 |
GROUND WIRE |
| 4 |
0171658 |
CRADLE & PAD |
| 5 |
0171672 |
STRAP & BUCKLE |
| 5 |
0975486 |
STRAP & BUCKLE FOR 18 GALLON FUEL TANK, HORIZONTAL |
| 8 |
0310128 |
HOSE |
| 9 |
0310129 |
GROUND STRAP |
| 10 |
0376623 |
SHUT-OFF VALVE ASSY NOTE: FOR TWIN MOTOR INSTALLATION |
| 11 |
0976904 |
FUEL GAUGE |
| 12 |
0379378 |
LEAD |
| 13 |
0900009 |
CLAMP |
| 14 |
0900132 |
PAD |
| 15 |
0900171 |
HEX NUT |
| 16 |
0900172 |
NUT |
| 17 |
0901463 |
CLAMP |
| 18 |
0900545 |
SCREW |
| 19 |
3852420 |
LOCKNUT, Throttle lever This part replaces 0900402. |
| 20 |
0900513 |
CONTACT |
| 21 |
0900984 |
EYEBOLT |
| 22 |
0901871 |
DECLECTOR, Vent fitting, white |
| 23 |
0902087 |
HOSE |
| 24 |
0975046 |
THRU HULL VENT ASSY, White |
| 26 |
0975446 |
FUEL FILLER |
| 27 |
0901224 |
SCREW |
| 28 |
0171673 |
FUEL TANK |
| 28 |
0976021 |
FUEL TANK FOR 18 GALLON FUEL TANK, HORIZONTAL |
| 29 |
0171649 |
MOUNTING PLATE |
| 30 |
0171675 |
SENDING UNIT |
| 30 |
0976024 |
SENDING UNIT FOR 18 GALLON FUEL TANK, HORIZONTAL |
| 31 |
0171676 |
WITHDRAWAL TUBE |
| 33 |
0305873 |
FASTENER |
| 34 |
0307466 |
SCRES, Bowl to body |
| 36 |
0900491 |
SUPPORT RING |
| 37 |
0900493 |
GASKET |
| 39 |
0900959 |
ELBOW |
| 0171655 |
0171655 |
FUEL TANK KIT, 18 gallon, horizontal FOR 18 GALLON FUEL TANK, HORIZONTAL |
| 0171677 |
0171677 |
FUEL TANK KIT, 24 gallon, horizontal |
