| Ref | Part Number | Description |
|---|
| 1 |
CAPSCREW, |
Hex hd., 1/4-20 x 3/4" long |
| 2 |
CAPSCREW, |
Hex hd., 1/4-20 x 1/2" long |
| 3 |
CAPSCREW, |
Hex hd., 3/8 x 1-1/2" long |
| 4 |
CAPSCREW, |
Hex hd., 3/8 x 1-1/4" long |
| 9 |
CLAMP, |
Hose, #10 |
| 10 |
CLAMP, |
Hose, #16 |
| 11 |
CLAMP, |
Hose, #24 |
| 12 |
HOSE, |
Flex., 1" i.d. 12-1/4" long |
| 13 |
HOSE, |
Flex., 5/8" i.d. 8" long |
| 14 |
HOSE, |
Flex., 1-1/2" i.d. 30" long |
| 15 |
HOSE, |
Flex., 1-1/2" i.d. 18-1/2" long |
| 16 |
HOSE, |
Flex., 5/8" i.d. 9" long |
| 17 |
NIPPLE, |
Hose connector |
| 18 |
047-022 |
HOUSING, Thermostat |
| 19 |
079-035 |
GASKET, Thermostat housing |
| 20 |
044-015 |
BRACKET, Mounting, AL - 18 |
| 21 |
072-005 |
HEADER ASSY, Water pump |
| 22 |
HEAT |
EXCHANGER ASSY., Omc 418-6 |
| 23 |
ADAPTER, |
Hose, 1-1/2" o.d. to 1-3/4" o.d. |
| 24 |
HOSE, |
Clear plastic |
| 25 |
072-019 |
THERMOSTAT, 160 deg f |
| 26 |
076-007 |
ANODE (INSTALLED IN HEAD EXCHANGER) |
