| Ref | Part Number | Description |
|---|
| 1 |
5032253 |
TILLER HANDLE KIT |
| 1 |
5032254 |
TILLER HANDLE KIT |
| 7 |
*5031765 |
BRKT,FRONT PANEL |
| 31 |
*5031787 |
COVER,TRIM SWITCH |
| 34 |
*5031606 |
GROMMET |
| 37 |
*5031791 |
E-RING |
| 38 |
*5031792 |
HOLDER, REMOTE CABLE |
| 39 |
*5031793 |
STOP, REMOTE CABLE |
| 40 |
*5032155 |
CONN,THROTTLE LIMT This part replaces 5032465. |
| 41 |
*5032289 |
PIN,CONNECTOR This part replaces 5032311. |
| 42 |
*5030049 |
SCREW (6X23mm) |
| 43 |
*5031794 |
WASHER |
| 44 |
*5031795 |
SPRING |
| 45 |
*5031796 |
BOLT |
| 46 |
*5031797 |
SCREW |
| 47 |
*5031798 |
SCREW |
| 48 |
*5031799 |
SCREW |
| 49 |
*5031609 |
BOLT |
| 50 |
*5035792 |
BOLT, (10X45mm) This part replaces *5030399. |
| 51 |
*5030054 |
NUT |
| 52 |
*5031080 |
WASHER,CONNECTOR |
| 53 |
*5031610 |
WASHER |
| 54 |
*5031612 |
BUSHING |
| 55 |
*5030575 |
CLIP |
| 56 |
*5031613 |
SPRING |
| 57 |
*5030414 |
SCREW, (6X30mm) |
| 58 |
*5031800 |
SCREW |
| 59 |
*5031801 |
SCREW |
| 60 |
*5031802 |
CLAMP |
| 61 |
5030204 |
AUTOCOLLANT, EMBRAYAGE |
| 62 |
*5030316 |
DECAL,HANDLE GRIP This part replaces 5031803. |
| 63 |
*5031736 |
STEERING FRICTION KIT |
| 64 |
*5032871 |
PLATE,LOCK This part replaces 5032461. |
| 65 |
*5032462 |
PLATE,BALL GUIDE |
| 66 |
*5032463 |
BALL |
