| Ref | Part Number | Description |
|---|
| 1 |
0397383 |
ENGINE COVER, Lower |
| 3 |
0331634 |
BAGUE, câble d'accélérateur |
| 4 |
0318286 |
CLAMP |
| 5 |
0909533 |
SCREW, Pressure relief valve cover |
| 6 |
0316354 |
ENGINE COVER SUPPORT GROMMET |
| 7 |
0304027 |
VIS, arbre de commande de sens de marche |
| 12 |
0316002 |
SUPPORT, Front port |
| 14 |
0327196 |
SUPPORT, Front stbd |
| 15 |
0302406 |
SLEEVE |
| 16 |
0551793 |
SCREW |
| 17 |
0303398 |
VIS, support |
| 18 |
0332169 |
SEAL, Steering arm |
| 19 |
0323474 |
HOOK, Cover to housing |
| 20 |
0323474 |
HOOK, Cover to housing |
| 23 |
0330151 |
CLAMP, Harness to oil tank boss |
| 24 |
0551793 |
SCREW |
| 25 |
0307769 |
PLUG |
| 25 |
0335653 |
GROMMET, AC Lighting |
| 26 |
0328731 |
VIS, câble de verrouillage |
| 27 |
0328456 |
CLAMP |
| 28 |
0436201 |
CABLE |
| 29 |
0329590 |
SPACER, Clamp |
| 30 |
0337505 |
GROMMET, Bracket |
| 31 |
0337504 |
BRACKET, Cyl. head to lower cover, starboard |
| 32 |
0337503 |
BRACKET, Cyl. head to lower cover, port |
| 33 |
0333739 |
RETAINER, Fuel hose to cover |
| 34 |
0310539 |
SCREW, Clamp choke solenoid |
