| Ref | Part Number | Description |
|---|
| 044 |
515175231 |
Female Terminal |
| 054 |
515175495 |
Female Housing, 3 Circuits |
| 062 |
278001014 |
Female Terminal |
| 073 |
278001013 |
Wire Seal |
| 075 |
409010700 |
Female Terminal |
| 079 |
710000038 |
Female Terminal |
| 099 |
278000992 |
Open Barrel |
| 109 |
409209900 |
Female Housing, 5 Circuits |
| 110 |
278000631 |
Male Terminal |
| 114 |
409206900 |
Male Housing, 2 Circuits |
| 126 |
409207500 |
Male Lock, 2 Circuits |
| 180 |
278001638 |
FEMALE TERMINAL - Call your local BRP dealership |
| 183 |
710000189 |
WIRE SEAL - Call your local BRP dealership |
| 184 |
710000668 |
CAP - Call your local BRP dealership |
| 186 |
219704424 |
Vinyl Tubing, Low Temp 3000Mm Long |
| 222 |
409204300 |
Female Housing |
| 227 |
409004300 |
Male Terminal |
| 230 |
278000161 |
Female Housing, 1 Circuit |
| 231 |
278000217 |
Female Housing, 2 Circuits |
| 242 |
278000218 |
Wire Seal |
| 243 |
710000048 |
Wire Seal |
| 253 |
219704425 |
Tubing 6 Mm 3000Mm Long |
| 254 |
219704399 |
Was 409901700 Tubing (9 mm) |
| 255 |
219704400 |
Was 409901800 Tubing (13 mm) |
| 256 |
219704408 |
Tubing 16 Mm 1000Mm Long |
| 258 |
219704407 |
Tubing 10 MM 1000MM Long |
| 269 |
409011100 |
MALE TERMINAL - Call your local BRP dealership |
| 276 |
409207900 |
MALE HOUSING - Call your local BRP dealership |
| 278 |
409208500 |
SEAL - Call your local BRP dealership |
| 280 |
409012100 |
Female Terminal |
| 284 |
409012300 |
Seal |
| 296 |
278000770 |
Insulated Sheath |
| 297 |
278001007 |
Insulated Sheath |
| 300 |
278000343 |
Fuse, 15 Amperes |
| 301 |
409012700 |
Diode |
| 312 |
710000107 |
MALE HOUSING, 5 CIRCUITS - Call your local BRP dealership |
| 329 |
710000082 |
Female Terminal |
| 330 |
278001484 |
RUBBER CAP - Call your local BRP dealership |
| 331 |
219704446 |
PROTECTOR TUBE, 4MM 1000MM LONG - Call your local BRP dealership |
| 332 |
278001326 |
Fuse Holder Cap |
| 333 |
278001325 |
Fuse Holder |
| 334 |
710000081 |
Female Housing, 6 Circuits |
| 335 |
710000112 |
OPEN BARREL - Call your local BRP dealership |
| 336 |
710000115 |
Rubber Envelope Terminal |
| 337 |
710000113 |
Female Terminal |
| 338 |
710000114 |
FEMALE TERMINAL - Call your local BRP dealership |
| 339 |
278001012 |
Male Housing, 1 Circuit |
| 340 |
278001443 |
Fuse, 25 Amperes |
| 342 |
710000190 |
FEMALE HOUSING, 6 CIRCUITS - Call your local BRP dealership |
| 343 |
710000191 |
LOCK, 6 CIRCUITS - Call your local BRP dealership |
| 400 |
278001576 |
MALE TERMINAL - Call your local BRP dealership |
| 401 |
278001505 |
WIRE SEAL - Call your local BRP dealership |
| 435 |
409009500 |
FEMALE TERMINAL - Call your local BRP dealership |
| 456 |
278000805 |
Cushion |
| 525 |
710000482 |
SHRINK TUBING - Call your local BRP dealership |
| 527 |
710000484 |
Shrink Tubing |
| 550 |
710000499 |
FEMALE HOUSING, 3 CIRCUITS - Call your local BRP dealership |
| 551 |
710000500 |
MALE TERMINAL - Call your local BRP dealership |
| 596 |
710000670 |
CAP - Call your local BRP dealership |
| 648 |
278001009 |
Female Terminal |
| 678 |
710000750 |
Shrink Tubing |
| 679 |
219704448 |
SHRINK TUBING 500MM LONG - Call your local BRP dealership |
