05- Suspension - Rear Shocks
Parts (24)
| Ref | Part Number | Description |
|---|---|---|
| 6 | 0324677 | JOINT TORIQUE, mamelon, vidange inférieure |
| 8 | 0324678 | JOINT TORIQUE Galet de came de papillon |
| 28 | 0394176 | TRIM /TILT MOTOR |
| 40 | 0360252 | WASHER This part replaces 0306311. |
| 44 | 0325698 | CONNECTOR |
| 55 | 0321246 | BUSHING, Shock absorber, lower |
| 72 | 0321219 | VIS, vis de fixation |
| 76 | 0512790 | SLEEVE, Motor & sending leads |
| 5000 | 619330026 | Center Shock |
| 5010 | 503193292 | Spring 220 MM-30 N/MM |
| 5060 | 503196528 | Stopper Spring |
| 5080 | 503195134 | Glide Bearing |
| 5090 | 5446652 | Bushing |
| 5150 | 40134 | Screw Socket HD.DIN 912 |
| 5160 | 232500416 | Elastic Stop Nut M10 |
| 5500 | 619330032 | Rear Shock |
| 5510 | 503196071 | Spring 330 MM-50 N/MM |
| 5560 | 503196528 | Stopper Spring |
| 5570 | 5446652 | Bushing |
| 5580 | 503195134 | Glide Bearing |
| 5590 | 40134 | Screw Socket HD.DIN 912 |
| 0398424 | 0434803 | HYDRAULIC ASSY., Trim/tilt This part replaces 0398424. |
| 0398606 | 0398606 | BRUSH & SEAL KIT |
| 0583522 | 0583522 | BRUSH & SEAL KIT |
