| Ref | Part Number | Description |
|---|
| 7 |
0912152 |
HOSE, Control valve to adapter |
| 8 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 10 |
0330366 |
HOSE, Control valve to cover |
| 11 |
0331216 |
HOSE, Control valve to tee |
| 12 |
0331933 |
HOSE, Adapter to control valve |
| 15 |
0912064 |
SLEEVE, Oil cooler |
| 16 |
0912000 |
ELBOW, Oil cooler |
| 20 |
0912329 |
SLEEVE, Return tube |
| 21 |
0984190 |
TUBE ASSY., Engine cover to oil cooler |
| 22 |
0984171 |
HOSE, Return tube to valve hsg. |
| 23 |
0984191 |
HOSE, Pressure hose to valve hsg. |
| 24 |
0912226 |
GROMMET, Return tube |
| 26 |
0325115 |
SCREW, Oil tank/EMM mount |
| 30 |
0394407 |
CONTROL VALVE |
| 31 |
0331887 |
HOSE, Overboard |
