| Ref | Part Number | Description |
|---|
| 100b |
250000958 |
Panel Nut M5 X 0.8 |
| 110 |
250100208 |
Panel Nut M6 X 1.0 |
| 300b |
250000958 |
Panel Nut M5 X 0.8 |
| 310 |
250100208 |
Panel Nut M6 X 1.0 |
| 500 |
250000758 |
Torx Screw M6 X 25 |
| 510 |
233261494 |
Hex. Flange Elastic Nut M6 |
| 600 |
708400208 |
Upper Fairing |
| 610 |
250100208 |
Panel Nut M6 X 1.0 |
| 710 |
250100208 |
Panel Nut M6 X 1.0 |
| 800 |
709402141 |
Rear Gauge Trim |
| 810 |
250000722 |
Torx Screw M6 X 20 |
| 815 |
250000722 |
Torx Screw M6 X 20 |
| 900 |
708400053 |
LH Slider Support |
| 910 |
250000807 |
Torx Truss Screw M6 X 25 |
| 920 |
250001131 |
Torx Truss PT K40 x 12 |
| 1000 |
708400054 |
RH Slider Support |
| 1010 |
250000807 |
Torx Truss Screw M6 X 25 |
| 1020 |
250001131 |
Torx Truss PT K40 x 12 |
| 1200 |
709402142 |
Front Gauge Trim |
| 1230 |
250001131 |
Torx Truss PT K40 x 12 |
| 1235 |
250001131 |
Torx Truss PT K40 x 12 |
| 1700 |
708400341 |
Deep Black, LH Consol Fairing |
| 1720 |
293150230 |
Tuflok Plastic Rivet |
| 1800 |
708400339 |
Deep Black, RH Consol Fairing |
| 1820 |
293150230 |
Tuflok Plastic Rivet |
| 2070 |
705012349 |
Deep Black, LH Trim Gauge |
| 2080 |
705012351 |
Deep Black, RH Trim Gauge |
| 2600 |
708400011 |
Black Deep Nose Fairing |
| 2610 |
250001131 |
Torx Truss PT K40 x 12 |
| 2615 |
250001131 |
Torx Truss PT K40 x 12 |
| 2620 |
250000762 |
Torx Screw M5 X 25 |
| 2630 |
233251494 |
Elastic Flange Nut M5 |
| 2700 |
708400016 |
LH Upper Console Header |
| 2710 |
250000578 |
Torx Truss Screw M5 X 16, T25 |
| 2712 |
234051670 |
Flat Washer M5 |
| 2714 |
250100152 |
Cap Nut M5 |
| 2720 |
250000842 |
Stainless, Torx Screw M6 X 30 |
| 2730 |
250001131 |
Torx Truss PT K40 x 12 |
| 2740 |
250000732 |
Torx Screw Nylon |
| 2800 |
708400017 |
RH Upper Console Header |
| 2810 |
250000578 |
Torx Truss Screw M5 X 16, T25 |
| 2812 |
234051670 |
Flat Washer M5 |
| 2814 |
250100152 |
Cap Nut M5 |
| 2820 |
250000842 |
Stainless, Torx Screw M6 X 30 |
| 2830 |
250001131 |
Torx Truss PT K40 x 12 |
| 2840 |
250000732 |
Torx Screw Nylon |
| 2900 |
705015049 |
LH Housing Rear View Mirror Ass'y |
| 3200 |
705015050 |
RH Housing Rear View Mirror Ass'y |
| 3500 |
250000793 |
Hex. Flange Screw M6 X 25 |
| 3505 |
210261650 |
Hex. Flange Screw M6 X 16 |
| 3510 |
250100208 |
Panel Nut M6 X 1.0 |
| 3600 |
250000793 |
Hex. Flange Screw M6 X 25 |
| 3605 |
210261650 |
Hex. Flange Screw M6 X 16 |
| 3610 |
250100208 |
Panel Nut M6 X 1.0 |
| 3800a1 |
708400205 |
Switch Bezel |
| 3800c |
704908774 |
Rear Fog Light Decal |
| 4000a |
708400238 |
Black Polycarbonate, LH Acces Panel |
| 4000b |
708400065 |
Cover Latch Quarter Turn |
| 4100a |
708400239 |
Black Polycarbonate, RH Acces Panel |
