| Ref | Part Number | Description |
|---|
| 1 |
219704453 |
Was 293550004 Dielectric Grease, 150 g |
| 23 |
409004200 |
Female Terminal |
| 24 |
278000992 |
Open Barrel |
| 25 |
409004000 |
Fuse Holder |
| 26 |
410917200 |
Fuse, 30 Amperes |
| 27 |
409014200 |
CLIP - Call your local BRP dealership |
| 34 |
250000282 |
Battery Bolt Kit This part replaces 295500849. |
| 36 |
278001680 |
Ground Cable Battery, no 6, meter) |
| 37 |
278001690 |
Cable Battery, no 6, meter) |
| 38 |
278001682 |
Terminal 45°, Small Hole |
| 39 |
219704447 |
Was 710000483 Heat Shrink Tubing |
| 278001685 |
FLAT |
TERMINAL, BIG HOLE - Call your local BRP dealership 278001685 |
| 278001685 |
Terminal |
Plate, Gros Trou - Appelez votre concessionnaire BRP local 278001685 |
| 278001688 |
FLAT |
TERMINAL - Call your local BRP dealership 278001688 |
| 278001688 |
Terminal |
Plat - Appelez votre concessionnaire BRP local 278001688 |
