| Ref | Part Number | Description |
|---|
| 1 |
0172093 |
LEVER, Idle adjustment |
| 2 |
0121893 |
HOUSING, Shift control |
| 3 |
0308038 |
VIS, butée de ralenti |
| 4 |
0121899 |
KNOB |
| 5 |
0172096 |
HANDLE ASSEMBLY |
| 6 |
0121275 |
SPRING, Detent |
| 7 |
0121276 |
GLIDER DETENT |
| 8 |
0121294 |
SCREW |
| 9 |
0121281 |
LEVER, Throttle friction |
| 10 |
0172092 |
SHIFT LEVER ASSEMBLY |
| 12 |
0121268 |
BUSHING |
| 13 |
0121895 |
ROLLER |
| 14 |
0121280 |
ECCENTRIC, Idle |
| 15 |
0121283 |
SCREW |
| 16 |
0121279 |
U-LINK, Throttle |
| 17 |
0311034 |
RETAINER RING |
| 18 |
0311057 |
WASHER |
| 19 |
0171814 |
LEVER, Throttle assembly |
| 20 |
0121898 |
WASHER, Idle link |
| 21 |
0121284 |
SCREW |
| 24 |
0121291 |
EMBLEM, Johnson |
| 24 |
0121292 |
EMBLEM, Evinrude |
| 25 |
0121271 |
WASHER, Idle spring |
| 26 |
0171693 |
IDLE LINK ASSEMBLY |
| 27 |
0121892 |
HOUSING, Throttle control |
| 28 |
0121285 |
SCREW |
| 30 |
0121900 |
SPRING, Throttle friction |
| 32 |
0205036 |
CASING GUIDE, Control |
| 33 |
0121282 |
SCREW |
| 34 |
0385958 |
CLAMP & SC R.,Casing guide |
| 36 |
0310685 |
ABCHOR BLCOK, Trunnion |
| 37 |
0310687 |
DETENT SPRING, Anchor block |
| 38 |
0310686 |
SCREW |
| 39 |
0310688 |
SAPCER, Anchor block |
| 41 |
0173506 |
SCREW This part replaces 0303222. |
| 42 |
0173506 |
SCREW |
| 44 |
0307063 |
O RING |
| 48 |
0308078 |
CLAMP |
| 51 |
0307063 |
O RING |
| 52 |
0121270 |
WASHER, Idle friction |
| 54 |
0309724 |
ANCHOR BLOCK |
| 0172079 |
0172079 |
SINGLE LEVER KIT |
| 0172097 |
0172097 |
DECAL SET |
| 0381444 |
0381444 |
CASING GUIDE |
