| Ref | Part Number | Description |
|---|
| 2 |
0583914 |
FLYWHEEL ASSEMBLY |
| 3 |
0582508 |
COIL ASSY |
| 4 |
0329241 |
RONDELLE |
| 5 |
0329176 |
FIBER WASHER, Ignition coil |
| 6 |
0582365 |
H.T. LEAD ASSEMBLY, Spark plugs to ignition coil |
| 10 |
515178227 |
Multifunction Gauge Full Size Color |
| 13 |
0303212 |
VIS, collier & capot |
| 14 |
0511458 |
COLLIER, fils |
| 15 |
0511459 |
CACHE, fils |
| 16 |
0337522 |
VIS, ensemble bobine |
| 17 |
0513029 |
SPACER |
| 18 |
0584472 |
ENSEMBLE FILS, masse |
| 19 |
0324386 |
CONNECTOR, Cable |
| 20 |
0324665 |
SCREW, Power pack to bracket |
| 21 |
0324673 |
LEVER, Throttle control |
| 22 |
0584488 |
IGNITION MODULE |
| 30 |
0513109 |
TUBING, Models leads |
| 33 |
0512741 |
DISPOSITIF DE RETENUE, conn. de l'interrupteur thermostatique |
| 34 |
0584333 |
CHARGE COIL & LAM. ASSY. |
| 37 |
0583285 |
PLAT & SLEEVE ASSY. |
| 38 |
0511460 |
VIS, dispositif de retenue |
| 39 |
0322285 |
PLATE & SLEEVE ASSY. |
| 40 |
0333704 |
CAM |
| 41 |
0331832 |
RETAINER |
| 43 |
0324384 |
CONNECTOR, Cable |
| 44 |
0324671 |
LINK, Connector |
| 45 |
0332070 |
SCREW, Retaining plate This part replaces 0326875. |
| 46 |
0332063 |
PLATE, Support |
| 47 |
0322435 |
ROULEMENT, plaque d'allumage vers support |
| 48 |
0333817 |
SPACER, Front |
| 49 |
0333816 |
SPACER, Rear |
| 50 |
0380226 |
REATINER ASSEMBLY |
| 51 |
0324668 |
LINK, Throttle lever |
| 52 |
0337521 |
SCREW, Module |
| 53 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 54 |
0306413 |
WASHER |
| 60 |
515178965 |
Gauge Support |
| 70 |
250000725 |
Screw M4 X 16 |
| 600 |
710006855 |
Ignition Switch |
| 610 |
278004274 |
Specialized Nut |
| 620 |
515179476 |
Grey, LYNX DESS Key |
| 800 |
515178645 |
Heated Visor Wiring Harness |
| 810 |
572103300 |
Cap |
| 1000 |
219400510 |
USB Outlet |
| 1010 |
515178190 |
Harness |
| 1040 |
515178153 |
Extension Harness |
| 1050 |
515178608 |
Seat Wiring Harness |
| 1060 |
515179490 |
Heated Seat Switch This part replaces 515178502. |
| 2400 |
515178969 |
Housing |
| 2410 |
515177147 |
Housing Plate |
| 2420 |
250000671 |
Torx Screw |
| 2470 |
415130141 |
Sleeve |
| 2480 |
415130141 |
Sleeve |
| 2600 |
515177931 |
Emergency Stop Switch |
| 2610 |
515177310 |
Emergency Stop Switch Support |
| 2620 |
250000263 |
Torx Screw #8-18 |
| 2996 |
250000911 |
Hex. Flange Screw M5 X 16 |
| 3245 |
515178968 |
Rocker Switch |
| 3250 |
515178501 |
Rocket Switch |
| 3253 |
515178462 |
Switch Rocker Hand Warmer |
| 5000 |
420464172 |
ECM Module |
| 5020 |
512061397 |
Module Support |
