| Ref | Part Number | Description |
|---|
| 1 |
0384854 |
BODY ASSY., Upper |
| 1 |
0384855 |
BODY ASSY., Lower |
| 1 |
0385876 |
BODY ASSY., Lower, manual start |
| 9 |
0322182 |
CHOKE VALVE This part replaces 0313359. |
| 11 |
0387811 |
CHOKE SHAFT ASSY This part replaces 0384237. |
| 29 |
0315232 |
RETAINER , Needle valve stbd |
| 30 |
0385233 |
NEEDLE VALVE, Slow speed |
| 33 |
0383318 |
FLOAT CHAMBER ASSEMBLY |
| 33 |
0383319 |
FLOAT CHAMBER ASSEMBLY |
| 36 |
0307832 |
PLUG, Screw |
| 38 |
0314166 |
BEARING, Needle valve |
| 42 |
0325092 |
GASKET This part replaces 0314477. |
| 43 |
0316355 |
BUT, Carburetor mounting |
| 0384235 |
0384235 |
CARB ASSY., Upper |
| 0384236 |
0384236 |
CARB ASSY., Lower, elec start |
| 0385695 |
0385695 |
CARB ASSY., Lower, manual start |
