05- Drive Pulley, Kick Start
Parts (20)
| Ref | Part Number | Description |
|---|---|---|
| 1 | Not | Available As Spare Part - Pulley Ass'y |
| 2 | A22140133000 | Kick Starter Ratchet |
| 3 | A22106133000 | COOLING FAN - Call your local BRP dealership |
| 4 | A22102133000 | Drive Face |
| 5 | A964011420385 | BUSHING - Call your local BRP dealership |
| 6 | A22110133000 | Face Comp Movable Drive - Call Your Local BRP Dealership |
| 7 | A22121175000 | WEIGHT ROLLER - Call your local BRP dealership |
| 8 | A22132133000 | SIDE PIECE - Call your local BRP dealership |
| 9 | A22131133000 | Ramp Plate |
| 10 | A9405012000 | Hex. Flange Nut With Serration M12 |
| 11 | A941011222020 | WASHER FLATE - Call your local BRP dealership |
| 12 | A28251133000 | STARTER SPINDLE - Call your local BRP dealership |
| 13 | A28281133000 | STARTER SPRING - Call your local BRP dealership |
| 14 | A28255133000 | KICK BOSS COLLAR - Call your local BRP dealership |
| 15 | A96401141821 | Bushing |
| 16 | A941011421015 | WASHER FLAT - Call your local BRP dealership |
| 17 | A945111400S | CIRCLIP - Call your local BRP dealership |
| 18 | A28230133000 | KICK PIGNION ASSY - Call your local BRP dealership |
| 19 | A941011017010 | WASHER FLAT - Call your local BRP dealership |
| 20 | A28223133000 | CLIP PIGNION KICK - Call your local BRP dealership |
