| Ref | Part Number | Description |
|---|
| 1 |
0282884 |
ENGINE COVER ASSY., Evinrude |
| 1 |
0396705 |
ENGINE COVER ASSY., Johnson |
| 9 |
0122147 |
VIS, connecteur |
| 10 |
0320732 |
HOOK |
| 13 |
0317173 |
SEAL, Cover |
| 14 |
0325675 |
APPLIQUE, Front |
| 16 |
0312299 |
VIS, serre-câble |
| 17 |
0315151 |
APPLIQUE, Rear |
| 18 |
0301814 |
WASHE,Tilt handle |
| 25 |
0325972 |
COLLIER, câbles électriques |
| 26 |
0329443 |
COVER |
| 27 |
0323474 |
HOOK, Cover to housing |
| 28 |
0318262 |
GROMMET |
| 30 |
0311020 |
SCREW, Clamp |
| 31 |
0321356 |
BRACKET, Lower cover |
| 32 |
0317581 |
SCREW, Actuator cam |
| 33 |
0319389 |
GROMMET, Shifter lock |
| 34 |
0304027 |
VIS, arbre de commande de sens de marche |
| 35 |
0376349 |
FIL, masse |
| 36 |
0316354 |
ENGINE COVER SUPPORT GROMMET |
| 37 |
0302406 |
SLEEVE |
| 38 |
0324814 |
ECREW,Exhaust cover,1-1/2"long |
| 39 |
0321376 |
WASHER |
| 41 |
0311375 |
NUT |
| 42 |
0321885 |
NIPPLE |
| 43 |
0303398 |
VIS, support |
| 44 |
0312495 |
SCREW, Adapter to inner hsg. |
| 45 |
0322822 |
SPACER |
| 46 |
0322823 |
SPACER |
| 47 |
0322824 |
BAFFLE |
| 49 |
0317491 |
CAP PLUG, Lower cover |
| 50 |
0553770 |
SEAL, Lower cover, small |
| 51 |
SEAL, |
Cover, large |
| 52 |
0304019 |
CROMMET, CONTROL SHAFT |
| 0210373 |
0210373 |
OWNERS MANUAL, Evinrude |
| 0282504 |
0282504 |
DECAL SET, Evinrude |
| 0395298 |
0395298 |
DECAL SET, Johnson |
