| Ref | Part Number | Description |
|---|
| 10a |
715900118 |
Rubber Boot |
| 10b |
509000045 |
Oetiker Gear Clamp 36.1MM |
| 15 |
705401093 |
Rubber Boot |
| 16 |
293650199 |
Oetiker Gear Clamp |
| 20 |
705401969 |
Coupling Sleeve |
| 35 |
705500504 |
Fill Level Plug |
| 36 |
705500506 |
Copper Washer |
| 40a |
705401344 |
CV Joint |
| 40b |
715900602 |
RH Plunging Joint |
| 40c |
705401349 |
Circlip Joint |
| 40d |
705401345 |
Boot Kit, Wheel Side |
| 40e |
715900282 |
Oetiker Clamp |
| 40f |
715900283 |
Oetiker Clamp, Small |
| 40g |
705401346 |
Boot Kit, Differential Side |
| 40h |
715900284 |
Oetiker Clamp, Large |
| 40j |
715900261 |
Oetiker Clamp, Small |
| 45 |
705403307 |
LH Knuckle This part replaces 705402904. |
| 46 |
705403308 |
RH Knuckle This part replaces 705402905. |
| 50a |
705401344 |
CV Joint |
| 50b |
715900603 |
LH Plunging Joint |
| 50c |
705401349 |
Circlip Joint |
| 50d |
705401345 |
Boot Kit, Wheel Side |
| 50e |
715900282 |
Oetiker Clamp |
| 50f |
715900283 |
Oetiker Clamp, Small |
| 50g |
705401346 |
Boot Kit, Differential Side |
| 50h |
715900284 |
Oetiker Clamp, Large |
| 50j |
715900261 |
Oetiker Clamp, Small |
| 55 |
705402088 |
Sensor Support |
| 56 |
234081410 |
Flat Washer 8 mm |
| 57 |
250000874 |
Torx Truss M8 X 25 |
| 60 |
293350150 |
Ball Bearing This part replaces 293350118. |
| 70 |
293650138 |
Oetiker Gear Clamp 44.0MM |
| 80 |
293370019 |
Circlip |
| 100 |
230602546 |
Hex. Flange Screw M10 X 125 |
| 110 |
233201436 |
Hex. Flange Elastic Nut M10 |
| 115 |
207685544 |
Hex. Flange Screw M8 X 55 |
| 120 |
233281414 |
Hex. Flange Elastic Nut M8 |
| 150 |
250200171 |
Conical Spring Washer M18 |
| 160 |
232291413 |
Hex. Flange Castellated Nut M18 |
| 170 |
250400071 |
Cotter Pin |
| 240 |
250200102 |
Flat Washer M12 |
| 250 |
250001042 |
Hex Flange Screw M12 X 20 |
| 310 |
250200014 |
Flat Washer M10 |
| 320 |
250001046 |
Hex Flange Screw M10 X 20 S.Grip |
