| Ref | Part Number | Description |
|---|
| 1 |
0310972 |
HOSE, Inlet |
| 2 |
0310973 |
HOSE, Manifold lower to thermo upper |
| 3 |
0307899 |
CLAMP |
| 6 |
0380984 |
EXHAUST MANIFOLD AND STUD ASSEMBLY |
| 7 |
0310870 |
STUD |
| 8 |
0312149 |
CAP, Exhaust manifold, stbd |
| 9 |
0311130 |
GASKET |
| 10 |
0380985 |
HEAT EXCHANGER |
| 13 |
3852093 |
STUD, Lift bracket This part replaces 0310968. |
| 14 |
0311131 |
GASKET |
| 15 |
0312151 |
ELBOW, Exh. manifold-stbd. |
| 16 |
0310904 |
NIPPLE, Elbow |
| 17 |
0313085 |
HOSE |
| 18 |
0031094 |
CLAMP |
| 19 |
0312771 |
GUARD,Ring gear |
| 21 |
0312479 |
HOSE |
| 22 |
0312148 |
CAP, Exh. manifold-port |
| 23 |
0379756 |
SWITCH, Water temperature |
| 24 |
0311008 |
GASKET |
| 25 |
0310908 |
BRACKET |
| 26 |
0310909 |
BRACKET |
| 27 |
0310910 |
BRACKET |
| 28 |
0379867 |
GUARD |
| 29 |
0900289 |
FINISH, Washer, belt guard |
| 30 |
0203622 |
WASHER |
| 32 |
0900695 |
SCREW |
| 33 |
0311524 |
DECAL, Freezing temperature |
| 34 |
0103867 |
WASHER |
| 35 |
0310899 |
S:EEVE.SJPRT |
| 36 |
0310900 |
SLEEVE, Long |
| 37 |
0306453 |
LOCKWASHER, Fuel pump |
| 38 |
0311046 |
BELT |
| 39 |
0306369 |
SCREW |
| 41 |
0312150 |
ELBOW, Exh. manifold-port |
| 42 |
0306322 |
BOLT, Water pump |
| 43 |
0310923 |
REINFORCEMENT |
| 44 |
OIL |
FILTER (AC TYPE PF-10 OR PUROLATOR PER-5) |
| 45 |
0380993 |
WATER PUMP ASSEMBLY |
| 46 |
0312161 |
GASKET |
| 47 |
0302288 |
BOLT |
| 48 |
0310898 |
SCREW, Belt guard mount |
| 49 |
0300355 |
SCREW |
| 50 |
0319292 |
SCREW, Clamp This part replaces 0308762. |
| 51 |
0311565 |
HOUSING,Upper |
| 52 |
0311567 |
GASKET |
| 53 |
0383307 |
TERMOSTAT ASSEMBLY This part replaces 0379754. |
| 54 |
0310913 |
GASKET |
| 55 |
0311566 |
HOUSING,Lower |
| 56 |
0310902 |
GASKET |
| 57 |
1379743 |
BAFFLE, Oil pan |
| 58 |
1359065 |
PULLEY,Water pump |
| 59 |
1193862 |
GASKET |
| 60 |
1379350 |
HOUSING & SCREEN |
| 61 |
BOLT,Hex,1/4-20x9/16" |
Ref: 62 1370748 SWITCH,Oil pressure 1370748 |
| 63 |
1358238 |
GASKET |
| 64 |
1374509 |
OIL PAN ASSEMBLY |
| 65 |
1389969 |
KIT, Drain plug and gasket |
| 66 |
0513975 |
GASKET |
| 67 |
1199924 |
SCREW |
| 68 |
1368546 |
ROD,Crankcase oil gauge |
| 69 |
1365027 |
PULLEY |
| 70 |
1193214 |
PIN,Idler |
| 72 |
SHAFT |
AND GEAR (N.S.S.) |
| 73 |
1382218 |
GASKET |
| 74 |
1359260 |
COVER |
| 75 |
1368502 |
VALVE |
| 76 |
1359980 |
SPRING |
| 77 |
1196898 |
GASKET |
| 78 |
1194360 |
CAP |
| 0304913 |
0304913 |
SCREW, Mounting |
| 0310898 |
0310898 |
SCREW, Belt guard mount |
| 0379752 |
0379752 |
BELT GUARD & BRKT.ASS. |
| 0380484 |
0380484 |
THERMOSTAT HOUSING AND VALVE ASSEMBLY |
| 1396313 |
1396313 |
KIT, Oil pump |
