| Ref | Part Number | Description |
|---|
| 10 |
715011447 |
Deep Black, Chassis Kit |
| 10a1a69 |
293150293 |
Pop Rivet 3/16 X ,425 |
| 10a1b71 |
293150293 |
Pop Rivet 3/16 X ,425 |
| 10a1c17 |
293150293 |
Pop Rivet 3/16 X ,425 |
| 10a1d33 |
293150293 |
Pop Rivet 3/16 X ,425 |
| 10a1p |
293150293 |
Pop Rivet 3/16 X ,425 |
| 20 |
705212438 |
Retaining Plate |
| 40 |
705212518 |
Retaining Plate |
| 50 |
705209767 |
Retaining Plate |
| 60 |
705209773 |
Retaining Plate |
| 80 |
705210435 |
Interior Bumper Reinforcement |
| 85 |
207582044 |
Hex. Flange Screw M8 X 20, Scotch Grip |
| 95 |
233201466 |
Flange Elastic Nut M10 |
| 100 |
250100199 |
Insert Half Hex Body M6 x 1.0 |
| 105 |
207502546 |
Hex. Flange Screw M10 X 25 |
| 115 |
293150293 |
Pop Rivet 3/16 X ,425 |
| 120 |
390402300 |
Pop Rivet 3/16" |
| 170 |
250100199 |
Insert Half Hex Body M6 x 1.0 |
| 180 |
207582044 |
Hex. Flange Screw M8 X 20, Scotch Grip |
| 190 |
233181414 |
Hex. Flange Nut M8 |
| 195 |
250100118 |
Panel Nut M8 X 1.25 |
| 200 |
705209762 |
Front Bumper |
| 205 |
715010915 |
Deep Black, Front Bumper Kit |
| 210 |
705210586 |
Forged Tow Hook |
| 215 |
709402854 |
Bumper Cap |
| 220 |
250001240 |
Shoulder Screw M10 X 1.5 X 60 |
| 230 |
233201466 |
Flange Elastic Nut M10 |
| 300a6 |
293150293 |
Pop Rivet 3/16 X ,425 |
| 310 |
230500046 |
Hex. Screw M10 X 100, Scotch Grip |
| 320 |
233101466 |
Hex. Flange Nut M10 |
| 330 |
230500046 |
Hex. Screw M10 X 100, Scotch Grip |
| 400g |
705210258 |
Black, Over Mounting Clamp |
| 400h |
705210259 |
Black, Over Mounting Clamp |
| 400j10 |
250000751 |
Torx Screw M8 X 16 |
| 400j11 |
705211104 |
Formed Shim |
| 400j12 |
293730062 |
Dart |
| 400j3 |
705210355 |
Molded Plug |
| 400j4 |
705210528 |
Molded Cover |
| 400j5 |
233201466 |
Flange Elastic Nut M10 |
| 400j7 |
232561494 |
Elastic Stop Nut M6 |
| 440 |
715010928 |
Deep Black, LH Cage Kit |
| 440a1p |
293150293 |
Pop Rivet 3/16 X ,425 |
| 450 |
715010378 |
Deep Black, RH Cage Kit |
| 450a1p |
293150293 |
Pop Rivet 3/16 X ,425 |
| 460 |
715010372 |
Deep Black, Central Cage Kit |
| 460a1r |
390402000 |
Pop Rivet 3/16" |
| 1050a |
250001195 |
Elastic Flange Nut M12 |
| 1050b |
207523056 |
Hex. Flange Screw M12 X 30, Scotch Grip |
| 1050c |
250000857 |
Flange Screw M12 X 60 |
| 1060a |
250000722 |
Torx Screw M6 X 20 |
| 1060b |
250100208 |
Panel Nut M6 X 1.0 |
| 1060c |
517306478 |
Clip |
| 9500a |
705017709 |
LH Central Cage Trim |
| 9500b |
705017710 |
RH Central Cage Trim |
| 9500c |
705017711 |
LH Central Cage Trim |
