| Ref | Part Number | Description |
|---|
| 27 |
XXX |
Not Available As Spare Parts |
| 33 |
207142544 |
Hex. Screw M4 X 25 |
| 37 |
207562034 |
Hex. Flange Screw M6 X 20, Scotch Grip |
| 38 |
207562034 |
Hex. Flange Screw M6 X 20, Scotch Grip This part replaces 207562044. |
| 43 |
XXX |
Not Available As Spare Parts |
| 44 |
207662054 |
Hex. Flange Screw M6 X 20 |
| 49 |
XXX |
Not Available As Spare Parts |
| 58 |
XXX |
Not Available As Spare Parts |
| 62 |
232561434 |
Elastic Stop Nut M6 |
| 63 |
233251434 |
Flange Elastic Nut M5 |
| 66 |
234001410 |
Flat Washer 10 mm |
| 69 |
234051600 |
Flat Washer M5, Stainless |
| 71 |
234052600 |
Flat Washer 5 mm, Stainless |
| 74 |
234062410 |
Flat Washer 6 mm |
| 81 |
250000750 |
Torx Screw M4 X 16 This part replaces 250000242. |
| 82 |
250000755 |
Torx Screw M6 X 16 This part replaces 250000261. |
| 85 |
250000577 |
Torx Truss Screw K40 X 12 |
| 87 |
250100198 |
Panel Nut M6 X 1.0 This part replaces 250100113. |
| 88 |
250100143 |
Extruded Panel Nut M4 X 0.7 |
| 91 |
XXX |
Not Available As Spare Parts |
| 100 |
710007256 |
Actuator Motor This part replaces 278003071. |
| 103 |
293150150 |
Pop Rivet |
| 113 |
293750002 |
Tie Wrap 142 mm |
| 126 |
293750009 |
Tie-Rap 173 mm |
| 145 |
293750058 |
Tie Rap 2 Pièces pour Bordure |
| 165 |
414115200 |
Tie-Rap 180 mm |
| 202 |
414227300 |
Clip |
| 206 |
XXX |
Not Available As Spare Parts |
| 246 |
XXX |
Not Available As Spare Parts |
| 248 |
705202617 |
RH RADIO SUPPORT - Call your local BRP dealership |
| 249 |
705202618 |
LH RADIO SUPPORT - Call your local BRP dealership |
| 252 |
705601344 |
Deflector |
| 253 |
705601402 |
LPS Deflector |
| 254 |
709401318 |
GPS SUPPORT, BLACK - Call your local BRP dealership |
| 298 |
XXX |
Not Available As Spare Parts |
| 299 |
XXX |
Not Available As Spare Parts |
| 360 |
710001248 |
DC Outlet |
| 361 |
XXX |
Not Available As Spare Parts |
| 362 |
XXX |
Not Available As Spare Parts |
| 372 |
XXX |
Not Available As Spare Parts |
| 373 |
XXX |
Not Available As Spare Parts |
| 394 |
219704354 |
Trim 1000Mm Long |
| 397 |
XXX |
Not Available As Spare Parts |
| 413 |
XXX |
Not Available As Spare Parts |
| 419 |
XXX |
Not Available As Spare Parts |
| 420 |
710007173 |
Plug Carling This part replaces 710001999. |
| 424 |
XXX |
Not Available As Spare Parts |
| 426 |
710002033 |
Connector Holder |
| 429 |
219400315 |
WEATHERCAP - Call your local BRP dealership |
| 437 |
710002288 |
PANEL SEAL - Call your local BRP dealership |
| 438 |
710002354 |
Switch, Heat Grip |
| 466 |
710004214 |
PBM MODULE - Call your local BRP dealership |
| 468 |
XXX |
Not Available As Spare Parts |
| 471 |
710002896 |
Tie-Rap Clip |
| 480 |
710002899 |
Clip Tie-Rap |
| 490 |
415129349 |
Lens |
| 515 |
710003232 |
Rear Speaker |
| 516 |
710003248 |
Antenna Support |
| 517 |
710003249 |
ANTENNA CABLE ASS'Y - Call your local BRP dealership |
| 520 |
219800399 |
REBUILT RADIO MODULE 5V IPOD - Call your local BRP dealership This part replaces 710004211. |
| 522 |
710003304 |
ANTENNA - Call your local BRP dealership |
| 530 |
710003347 |
ANTENNA STOPPER - Call your local BRP dealership |
| 537 |
710003412 |
Brake Light Switch Ass'y |
| 560 |
XXX |
Not Available As Spare Parts |
| 578 |
XXX |
Not Available As Spare Parts |
| 597 |
710004758 |
WIRING HARNESS_RADIO - Call your local BRP dealership This part replaces 710004366. |
| 607 |
232541414 |
Elastic Stop Nut M4 |
| 609 |
XXX |
Not Available As Spare Parts |
| 611 |
219800280 |
Rubber Cap Protector |
| 612 |
515176274 |
Halogen Bulb, 60/55 W, 12 V ( H4 ) |
| 614 |
710003997 |
PROTECTOR BOOT - Call your local BRP dealership |
| 619 |
XXX |
Not Available As Spare Parts |
| 624 |
710004583 |
RH Switch Housing This part replaces 710004146. |
| 631 |
XXX |
Not Available As Spare Parts |
| 643 |
710004533 |
GPS Harness |
| 645 |
710004254 |
GPS Protector Support |
