| Ref | Part Number | Description |
|---|
| 75 |
409010700 |
Female Terminal |
| 77 |
409010300 |
Female Terminal |
| 88 |
278001009 |
Female Terminal |
| 101 |
278001392 |
Open Barrel Terminal |
| 112 |
278000632 |
Female Terminal |
| 123 |
710001540 |
CONNECTOR_MALE 6 CAVITIES - Call your local BRP dealership This part replaces 278000736. |
| 180 |
278001638 |
FEMALE TERMINAL - Call your local BRP dealership |
| 183 |
710000189 |
WIRE SEAL - Call your local BRP dealership |
| 202 |
278001114 |
Female Terminal |
| 222 |
409204300 |
Female Housing |
| 227 |
409004300 |
Male Terminal |
| 231 |
278000217 |
Female Housing, 2 Circuits |
| 242 |
278000218 |
Wire Seal |
| 253 |
219704425 |
Tubing 6 Mm 3000Mm Long |
| 254 |
219704399 |
Was 409901700 Tubing (9 mm) |
| 256 |
219704408 |
Tubing 16 Mm 1000Mm Long |
| 257 |
219704398 |
Was 409901600 Tubing 19mm |
| 280 |
409012100 |
Female Terminal |
| 284 |
409012300 |
Seal |
| 297 |
278001007 |
Insulated Sheath |
| 300 |
278000343 |
Fuse, 15 Amperes |
| 328 |
278001467 |
MALE TERMINAL HOUSING, 3 CIRCUITS - Call your local BRP dealership |
| 329 |
710000082 |
Female Terminal |
| 331 |
219704446 |
PROTECTOR TUBE, 4MM 1000MM LONG - Call your local BRP dealership |
| 332 |
278001326 |
Fuse Holder Cap |
| 333 |
278001325 |
Fuse Holder |
| 334 |
710000081 |
Female Housing, 6 Circuits |
| 336 |
710000115 |
Rubber Envelope Terminal |
| 337 |
710000113 |
Female Terminal |
| 338 |
710000114 |
FEMALE TERMINAL - Call your local BRP dealership |
| 342 |
710000190 |
FEMALE HOUSING, 6 CIRCUITS - Call your local BRP dealership |
| 343 |
710000191 |
LOCK, 6 CIRCUITS - Call your local BRP dealership |
| 394 |
710000275 |
Female Terminal Housing, 3 Circuits |
| 395 |
710000274 |
Female Terminal |
| 396 |
710000272 |
Female Terminal Housing, 4 Circuits |
| 397 |
710000273 |
Lock, 4 Circuits |
| 416 |
710000289 |
Spade Terminal |
