INSTRUMENTS SUN SHIELDED
Parts (12)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 0121703 | U BOLT |
| 4 | 0304141 | LOCKWASHER |
| 5 | 0132520 | NUT |
| 6 | 0121788 | SCREW |
| 8 | 0121869 | STUD |
| 12 | 0121720 | BITTON,Trim |
| 13 | 0172058 | CONNECTOR WIRE |
| 14 | 3853800 | OIL PRESSURE SENDER This part replaces 0172127. |
| 15 | 0171960 | SENDER, Water temperature |
| 16 | 0121687 | FITTING |
| 17 | 3855776 | ADAPTER, Oil sender This part replaces 0121688. |
| 0172075 | 0172075 | OIL PRESSURE,Water temp. guage kit |
