| Ref | Part Number | Description |
|---|
| 1 |
0323170 |
HOOK Front and stbd., rear |
| 4 |
0318849 |
CLAMP, Instrument cable |
| 5 |
0908159 |
SCREW, Bearing clamp |
| 8 |
0395758 |
LATCH HANDLE ASSY., Rear |
| 9 |
0333739 |
RETAINER, Fuel hose to cover |
| 10 |
0303398 |
VIS, support |
| 10 |
704909038 |
Emblem Logo BRP 20 MM UV |
| 13 |
0316354 |
ENGINE COVER SUPPORT GROMMET |
| 14 |
0302406 |
SLEEVE |
| 15 |
704909041 |
Emblem Logo BRP 68 MM UV |
| 16 |
0331533 |
JOINT, conn. carburant vers capot inférieur |
| 17 |
0323169 |
HOOK, Lower rear port |
| 18 |
0320521 |
GROMMET |
| 21 |
0395757 |
LATCH HANDLE ASSY., Front |
| 23 |
0323428 |
GROMMET |
| 25 |
0434289 |
COVER, Lower |
| 26 |
0332876 |
CAM, Throttle control |
| 28 |
0336526 |
PLUG, Cover |
| 29 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 30 |
704909040 |
Emblem BRP Logo 48 MM UV |
| 31 |
0512423 |
SLEEVE |
| 200 |
516009561 |
Upper Side Panel Decal "600R E-TEC" |
| 300 |
516010629 |
LH/RH Side Panel Decal "Lynx X Terrain" |
| 310 |
516010970 |
LH/RH Side Panel Decal |
| 600 |
516008760 |
Decal "Rotax Power" |
| 700 |
516010632 |
Tunnel Decal |
| 800 |
516010635 |
LH/RH Platform Decal |
| 1105 |
516011365 |
Clutch Instruction Label |
| 1110 |
516011437 |
Ramp Instruction Label |
| 1120 |
516011629 |
Tool Instruction Label |
| 1535 |
516009954 |
Protective Decal |
| 1540 |
516011681 |
Decal Q-Link |
| 1550 |
516011681 |
Decal Q-Link |
| 1560 |
516011681 |
Decal Q-Link |
