| Ref | Part Number | Description |
|---|
| 1 |
293710162 |
Fitting This part replaces 293710015. |
| 2 |
293250006 |
GASKET - Call your local BRP dealership |
| 3 |
296000309 |
Silicone Sealant 51388, 300 ml |
| 4 |
291001206 |
BILGEFLEX HOSE 3/4, BLACK, METER - Call your local BRP dealership |
| 5 |
293650016 |
Tridon Clamp |
| 6 |
414115200 |
Tie-Rap 180 mm |
| 7 |
204100028 |
Thru Hull Fitting 5/8" |
| 8 |
296000309 |
Silicone Sealant 51388, 300 ml |
| 9 |
293250028 |
GASKET - Call your local BRP dealership |
| 10 |
204050671 |
DECK SUPPORT ASS'Y. - Call your local BRP dealership |
| 11 |
296000309 |
Silicone Sealant 51388, 300 ml |
| 12 |
250000188 |
HEX. SCREW M10 X 50, SCOTCH GRIP - Call your local BRP dealership |
| 13 |
234002600 |
Flat Washer 10 mm, Stainless |
| 14 |
232501600 |
HEX. ELASTIC NUT M10 - Call your local BRP dealership |
| 15 |
296000309 |
Silicone Sealant 51388, 300 ml |
| 16 |
Not |
Available As Spare Part - Upper Deck Support |
| 17 |
234082600 |
Flat Washer 8 mm, Stainless |
| 18 |
207183560 |
HEX. SCREW M8 X 35 - Call your local BRP dealership |
| 19 |
234180602 |
Lock Spring Washer 8 mm, Stainless |
