| Ref | Part Number | Description |
|---|
| 6 |
512060934 |
Spring |
| 7 |
207561644 |
Hex. Flange Screw M6 X 16, Scotch Grip |
| 8 |
207562544 |
Hex. Flange Screw M6 X 25 |
| 9 |
207582044 |
Hex. Flange Screw M8 X 20, Scotch Grip |
| 10 |
207582586 |
Hex. Flange Screw M8 X 25, Scotch Grip |
| 11 |
207583544 |
Hex Flange Screw M8 X 35, Scotch Grip |
| 12 |
207652044 |
Hex.Flange Screw M5 X 20 |
| 13 |
207683044 |
Hex. Flange Screw M8 X 30 |
| 14 |
210251180 |
HEX. FLANGED SCREW M5 X 11 - Call your local BRP dealership |
| 15 |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 |
| 16 |
234001410 |
Flat Washer 10 mm |
| 18 |
241151640 |
Hex. Flange Screw K50 X 2.24 X 16 |
| 19 |
250000958 |
Panel Nut M5 X 0.8 This part replaces 250000079. |
| 20 |
250000752 |
Torx Screw M8 X 1.25 X 25, Scotch Grip This part replaces 250000248. |
| 21 |
250000253 |
Hex. Flange Screw M6 X 1.0 X 30 |
| 22 |
250000297 |
Truss Head Torx Screw K50 X 20 |
| 23 |
250000528 |
Torx Screw M5 X 20 |
| 24 |
250000796 |
Hex. Flange Screw M8 X 1.25 X 25 This part replaces 250000570. |
| 25 |
250200008 |
Flat Washer With Teflon 8 mm |
| 26 |
250200040 |
Flat Washer |
| 27 |
250200146 |
Conical Spring Washer M8 |
| 28 |
293100003 |
Nut Welded, M6 |
| 31 |
293650046 |
Oetiker Clamp |
| 32 |
293650158 |
Gemi Clamp |
| 34 |
293650214 |
Norma Spring Clamp |
| 36 |
293650234 |
Crimp Clamp |
| 37 |
293710068 |
T-Fitting |
| 38 |
293750001 |
Tie Wrap 94 mm |
| 47 |
293750008 |
Tie Wrap 368 mm |
| 92 |
414115200 |
Tie-Rap 180 mm |
| 93 |
414274500 |
Circlip |
| 95 |
414814100 |
Male Connector |
| 96 |
420430930 |
Gasket |
| 97 |
420441187 |
Torx Flange Screw M10 X 90 -SW 13/T50 |
| 99 |
420889201 |
Throttle Body This part replaces 420889197. |
| 105 |
420924724 |
Hose Nipple |
| 108 |
503183200 |
Yellow, Washer |
| 135 |
512061126 |
Ignition Cable, 177mm long This part replaces 512060094. |
| 148 |
512060298 |
Solenoid Support |
| 149 |
512060313 |
Protector |
| 150 |
512060339 |
NOISE SHIELD - Call your local BRP dealership |
| 151 |
512060343 |
Interior Noise Foam |
| 152 |
512060344 |
Upper Exterior Noise Foam |
| 153 |
512060362 |
LOWER EXTERIOR NOISE FOAM - Call your local BRP dealership |
| 154 |
512061507 |
Vibration Damper This part replaces 512060387. |
| 160 |
512060448 |
Rubber Mount |
| 165 |
512060469 |
Front Support, MAG |
| 166 |
512060478 |
Rear Support, PTO |
| 169 |
512060559 |
Rear Support, MAG |
| 170 |
512060574 |
Heat Shield |
| 171 |
512060575 |
Heat Shield |
| 172 |
512060576 |
Stopper Support |
| 173 |
512060611 |
Throttle Cable |
| 184 |
512061250 |
Handle Ass'y This part replaces 512060618. |
| 190 |
512060627 |
Stopper |
| 199 |
512060692 |
Manifold |
| 203 |
512060694 |
RH Formed Hose |
| 205 |
512060695 |
LH Formed Hose |
| 207 |
415130430 |
Spark Plug NGK PZFR6F This part replaces 415129375. |
| 208 |
512060712 |
FRONT SUPPORT PTO - Call your local BRP dealership This part replaces 512060699. |
| 210 |
219704352 |
Was 420660574 Pressure Hose 280 mm |
| 211 |
219704352 |
Was 420660574 Pressure Hose 280 mm |
| 213 |
219704352 |
Was 420660574 Pressure Hose 280 mm |
| 218 |
512060729 |
Rubber Mount |
| 222 |
512060780 |
Calibrated Module This part replaces 512060912. |
| 223 |
512060740 |
Formed Hose, Output |
| 224 |
219704408 |
Tubing 16 Mm 1000Mm Long |
| 225 |
219704410 |
Polyurethane Hose 10000Mm Long |
| 229 |
219704399 |
Was 409901700 Tubing (9 mm) |
| 231 |
512060769 |
Manifold Support |
| 232 |
270600005 |
Solenoid Valve This part replaces 512060950. |
| 237 |
512060827 |
Hose Support |
| 238 |
512060858 |
Calibrated Module Support |
| 239 |
512060859 |
Upper Housing |
| 241 |
512060860 |
Lower Housing |
| 243 |
512060953 |
Ignition Coil This part replaces 512060877. |
| 245 |
512060888 |
Ignition Coils Support |
| 246 |
512061233 |
Fuel Injector This part replaces 512060890. |
| 248 |
219704709 |
NEEDS DESCRIPTION This part replaces 219704409. |
| 249 |
219704399 |
Was 409901700 Tubing (9 mm) |
| 251 |
515176500 |
Washer |
| 253 |
515178473 |
Starter This part replaces 515177389. |
| 257 |
518325560 |
Adhesive Patch |
| 265 |
710000992 |
Clip |
| 266 |
732601143 |
Flange Screw |
