LOWER ENGINE COVER
Parts (24)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 5032118 | HOOK, INSTRUMENT PANEL |
| 2 | 5034712 | COVER, SIDE STBD (WHITE) |
| 4 | 5032130 | HOLDER, Side cover |
| 5 | 5032131 | HOLDER, Side cover |
| 6 | 5031569 | CUSHION, Cover, lower |
| 7 | 5035787 | PANEL, FRONT (WHITE) |
| 8 | 5032134 | BRACKET, Front panel |
| 9 | 5032135 | PROTECTION, CAPOT LATÉRAL |
| 10 | 5031824 | SCREW (6X30) |
| 11 | 5031906 | CLIP |
| 15 | 5032301 | BOLT |
| 16 | 5031690 | VIS |
| 17 | 5037516 | SCREW |
| 18 | 5032125 | HOOK, ENGINE COVER |
| 19 | 5032126 | LEVER, Hook rear |
| 20 | 5031821 | BOULON (6 x 12 mm) |
| 21 | 5031833 | WASHER (13.2X25X1.0) |
| 22 | 5031857 | WASHER, WAVE |
| 23 | 5031894 | BUSH |
| 25 | 5034716 | SEAL, SIDE COVER |
| 26 | 5032115 | CUSHION, SIDE COVER |
| 27 | 5032128 | PLUG, SIDE COVER |
| 28 | 5030120 | CUSHION |
| 29 | 5037462 | SCREW |
