| Ref | Part Number | Description |
|---|
| 1 |
0303887 |
WASHEER, Pin to swivel bracket |
| 2 |
0312329 |
NUT |
| 3 |
0910005 |
STUD |
| 4 |
0909662 |
SPACER, Stud to adapter housing |
| 7 |
0303398 |
VIS, support This part replaces 0302030. |
| 8 |
0303311 |
SCR,Clamp,eng cable |
| 9 |
0120590 |
WASHER LEVER ARM, Pulley |
| 10 |
0330995 |
RONDELLE, levier This part replaces 0308371. |
| 11 |
0318468 |
SCRAEW, Latch to handle |
| 12 |
0319658 |
COTTER PIN, Prop |
| 13 |
0600014 |
SCREW |
| 15 |
0981893 |
COVER, Shift housing |
| 16 |
0910524 |
SPRING, Cable to tensioner This part replaces 0909333. |
| 17 |
0909334 |
RACK, Cable tensioner |
| 18 |
0909335 |
PAWL, Tensioner, long |
| 19 |
0909336 |
SPRING, Tensioner |
| 20 |
0909337 |
PIN, Pawl to housing |
| 21 |
0909338 |
LINDER,Cable tensioner |
| 22 |
0910042 |
HITCH PIN, Cable retainer This part replaces 0909339. |
| 23 |
0909357 |
ROLL PIN, Rack to housing |
| 24 |
0909477 |
GUIDE, Cables |
| 25 |
0909599 |
PAUL,Tensioner,short |
| 26 |
0909790 |
RETAINER |
| 27 |
0981892 |
PULLEY SEGMENT & SHAFT ASSY |
| 28 |
0981322 |
HOUSING, Bearings & seal assy |
| 29 |
0981324 |
LEVER ARM & PIN ASSEMBLY |
| 30 |
0981346 |
IDELER PULLEY & BEARING ASSY |
| 31 |
3852421 |
SCREW, Baffle This part replaces 0907768. |
| 32 |
0909370 |
COVER, Flywheel |
| 33 |
0981552 |
ADAPTER HOUSING ASSY |
| 34 |
0909514 |
STUD |
| 35 |
0309614 |
DOWEL |
| 36 |
0909811 |
CLAMP, Exhaust seal |
| 37 |
0306993 |
L'WASHER,Potentiometer,12 V |
| 38 |
3852604 |
CLAMP, Exhaust This part replaces 0981323. |
| 39 |
0909347 |
CAP, Exhaust inlet, adapter |
| 40 |
0312178 |
SCREW |
| 40 |
0909571 |
SCREW |
| 42 |
0981927 |
ESHAUST ASSY |
