GEARS, COUNTER ROTATION
Parts (16)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 5034098 | HOUSING, BEARING |
| 8 | 5033846 | HOUSING |
| 11 | 5034099 | HOUSING, REV GEAR BEARING |
| 14 | 5031216 | BOLT |
| 15 | 5030398 | BOLT |
| 17 | 5032553 | COLLAR, DRIVE SHAFT |
| 22 | 5034100 | PINION/GEAR SET |
| 24 | 5030975 | SHIM KIT, Driveshaft |
| 31 | 5034119 | BEARING (60X85X3.0mm) Reverse |
| 32 | 5033986 | BEARING (70X95X4.0mm) Forward |
| 33 | 5034101 | SHAFT, PROPELLER |
| 34 | 5033953 | SHIFTER, CLUTCH DOG |
| 35 | 5033855 | PIN, CONNECTOR |
| 36 | 5032584 | PIN |
| 37 | 5034145 | SPRING |
| 38 | 5034102 | SPACER, CLUTCH DOG FWD |
