07- Suspension, Front - Shocks - Racing
Parts (18)
| Ref | Part Number | Description |
|---|---|---|
| 990 | 505074903 | RH Front Shock |
| 990a | 415093807 | O-Ring |
| 990b | 415093806 | Piston Ring |
| 990c | 505070398 | Air Valve |
| 990d | 505070399 | Screw |
| 990e | 505070400 | O-Ring |
| 990f | 715900076 | Circlip - Call your local BRP dealership |
| 990g | 415093804 | O-Ring |
| 1000 | 505074904 | LH FRONT SHOCK - Call your local BRP dealership |
| 1000a | 415093807 | O-Ring |
| 1000b | 415093806 | Piston Ring |
| 1000c | 505070398 | Air Valve |
| 1000d | 505070399 | Screw |
| 1000e | 505070400 | O-Ring |
| 1000f | 715900076 | Circlip - Call your local BRP dealership |
| 1000g | 415093804 | O-Ring |
| 1010 | 505074661 | Deep Black, Spring |
| 1040 | 505072635 | Spring Stopper |
