| Ref | Part Number | Description |
|---|
| 10b |
234042600 |
Flat Washer 4 mm, Stainless |
| 10c |
241142560 |
Hex. Flange Screw K40 X 25 |
| 10d |
291002818 |
DECK NOSE - Call your local BRP dealership |
| 10e |
291004291 |
Carpet |
| 10f |
291002930 |
LH Front Carpet |
| 10g |
291002931 |
ANTI SLIP MAT FR - Call your local BRP dealership |
| 10h |
291004359 |
ANTI SLIP MAT CTRL L - Call your local BRP dealership |
| 10j |
291004360 |
ANTI SLIP MAT CTRL R - Call your local BRP dealership |
| 10k |
291004361 |
ANTI SLIP MAT REAR L - Call your local BRP dealership |
| 10m |
291004362 |
ANTI SLIP MAT REAR R - Call your local BRP dealership |
| 10n |
291004336 |
Carpet |
| 10p |
291004337 |
Carpet |
| 10q |
291004295 |
LH SPACER - Call your local BRP dealership |
| 10r |
291004296 |
RH SPACER - Call your local BRP dealership |
| 10s |
250000879 |
Plastite Torx Screw M6.81X30 |
| 40 |
293250259 |
GASKET - Call your local BRP dealership |
| 50 |
293250365 |
NEOPRENE SEAL - Call your local BRP dealership |
| 60 |
293250200 |
NEOPRENE SEAL - Call your local BRP dealership |
| 65 |
293730010 |
Black Dart |
| 69 |
219704381 |
SEAL 1000MM LONG - Call your local BRP dealership |
| 70 |
291004595 |
Front Module |
| 73 |
269002893 |
CASE - Call your local BRP dealership |
| 74 |
293150123 |
Pop Rivet 3/16" |
| 75 |
291004210 |
SEAT PIVOT - Call your local BRP dealership |
| 76 |
293150123 |
Pop Rivet 3/16" |
| 80 |
243163560 |
Plastite Hex. Screw M6.8 X 35 |
| 90 |
234082600 |
Flat Washer 8 mm, Stainless |
| 250 |
291002626 |
LH Nonskid |
| 260 |
291002937 |
RH NONSKID - Call your local BRP dealership |
| 310 |
293150016 |
Rivet 1/8" |
| 320 |
293000014 |
Black, Snap Cap |
| 470a |
291004623 |
REAR HANDLE ASSY - Call your local BRP dealership |
| 470b |
291003878 |
Seat Stud |
| 470c |
232100600 |
Hex. Jam Nut M10 |
| 470d |
234002600 |
Flat Washer 10 mm, Stainless |
| 470e |
271001732 |
Elastic Nut M10 Housing |
| 475 |
219704378 |
Gasket 3000Mm Long |
| 485 |
207065560 |
Hex. Screw M6 x 55 |
| 490 |
234062600 |
Flat Washer M6, Stainless |
| 500 |
232561200 |
Brass Elastic Stop Nut M6 |
| 510 |
207164060 |
Hex. Screw M6 X 40 |
| 520 |
250200022 |
Flat Washer M6.6 X 22 |
| 750b |
269502408 |
Housing Nut M6 This part replaces 269501166. |
| 750c |
219903184 |
CAUTION ENGINE OIL - Call your local BRP dealership |
| 820 |
291004176 |
Front RH Cosmetic Ass |
| 830 |
291004177 |
FRONT LH COSMETIC ASS - Call your local BRP dealership |
| 850 |
293150123 |
Pop Rivet 3/16" |
| 950 |
291004638 |
LH COSMETIC - Call your local BRP dealership This part replaces 291004240. |
| 960 |
291004245 |
RH Cosmetic This part replaces 291004245. |
| 970 |
293150123 |
Pop Rivet 3/16" |
| 1030 |
291004275 |
Front Bumper |
| 1050 |
250000399 |
Hexagonal Cap Screw M6 X35 |
| 1060 |
291004274 |
Rear Bumper |
| 1080 |
250000399 |
Hexagonal Cap Screw M6 X35 |
| 1090 |
291004451 |
Black, Side Bumper |
| 1110 |
250000399 |
Hexagonal Cap Screw M6 X35 |
| 1160 |
291002744 |
Bumber Cap |
| 1300 |
513033435 |
Grommet |
| 1310 |
414523600 |
Elbow Fitting |
| 1320 |
219704356 |
Was 275500008 Hose 12 mm |
| 1330 |
293750001 |
Tie Wrap 94 mm |
| 1900b |
295100740 |
Replacing Kit for Pylon Strap This part replaces 293250183. |
| 1900f |
293250151 |
Seal |
| 1900h |
241141360 |
Hex. Flange Screw K40 X 13 |
| 1900j |
269501299 |
Strap |
| 1905a |
291004766 |
Molded Handle This part replaces 291002812. |
| 1905b |
291002642 |
ALUMINUM POST - Call your local BRP dealership |
| 1905c |
269501651 |
Ball Spring |
| 1905d |
293350062 |
Ball 1/4" |
| 1905e |
219903137 |
Warning Label |
| 1905f |
293150167 |
Type "U" Metallic Drive Screw |
| 1905g |
291001519 |
Bumper Plug, Black |
| 1910 |
250000452 |
Torx Screw M8 X 40, Stainless |
| 1915 |
293050001 |
Flat Washer M8.5 x 18 |
| 1920 |
234082600 |
Flat Washer 8 mm, Stainless |
| 1925 |
293830037 |
Rubber Washer |
| 1930 |
250200175 |
Flat Washer 8 mm, Stainless This part replaces 250200011. |
| 1940 |
232581200 |
Hex. Elastic Nut M8 Brass |
| 1950 |
291002711 |
Lateral Arm LH |
| 1960 |
291002712 |
Lateral Arm RH |
| 1970 |
230060060 |
Hex. Screw M6 X 100 |
| 1980 |
234062600 |
Flat Washer M6, Stainless |
| 1990 |
232561200 |
Brass Elastic Stop Nut M6 |
| 2050a1 |
291002979 |
Elastic Rope Ass'y |
| 2050a2 |
291002980 |
Latch |
| 2050a3 |
219903228 |
Warning WAKE |
| 2050a4 |
219903240 |
WAKE-PRO Decal |
| 2050a5 |
293830005 |
Rubber Bumper |
| 2050a6 |
293830119 |
Rubber Buffer |
| 2050a7 |
250000287 |
Flange Torx Screw K40 X 16 |
| 2050b |
291002864 |
Lower Anchorage |
| 2050c |
250000466 |
Torx Screw Plastite M6 |
| 2070 |
291003582 |
Upper Anchorage |
| 2080 |
250000466 |
Torx Screw Plastite M6 |
