| Ref | Part Number | Description |
|---|
| 1 |
0398191 |
GEARCASE & BEARING ASSY. |
| 2 |
0391471 |
BEARING, Pinion |
| 4 |
0331535 |
SCREEN, Water intake, stbd. |
| 5 |
0396228 |
SCREEN, Water intake, port |
| 11 |
0326807 |
DETENT, Shift |
| 15 |
0326823 |
SHAFT |
| 18 |
0395209 |
PROP SHAFT ASSY |
| 21 |
0431735 |
HOUSING & BEARING ASSY |
| 24 |
0432545 |
BEARING HSG. SEAL ASSY. |
| 28 |
0913432 |
SCREW |
| 29 |
0332091 |
RETAINER, Bearing housing |
| 32 |
0394836 |
GEAR & PINION ASSY. |
| 35 |
5000630 |
Driveshaft Ay This part replaces 0391494. |
| 35 |
5000634 |
Driveshaft Ay This part replaces 0391495. |
| 36 |
0327658 |
SHIFT ROD |
| 36 |
0327659 |
SHIFT ROD |
| 37 |
0327661 |
GEAR, Reverse |
| 44 |
0326733 |
THRUST WASHER |
| 48 |
0335020 |
SCREW, Bracket to block This part replaces 0318139. |
| 54 |
0397768 |
ANODE |
| 57 |
0335221 |
SCREW, Throttle body to reed plate This part replaces 0328715. |
| 60 |
0338742 |
COMPENSATEUR DE DÉRIVE This part replaces 0327640. |
| 63 |
0435027 |
CUP & PLATE This part replaces 0330379. |
| 63 |
0435526 |
CHROME CUP & PLATE KIT This part replaces 0330384. |
| 65 |
0313715 |
SCREW, Cap, hex hd, 7/16-14 x 1 |
| 70 |
0331998 |
SCREW, Gearcase to housing |
| 71 |
0331999 |
SCREW, Gearcase housing |
| 72 |
0331999 |
SCREW, Gearcase housing |
| 73 |
0331353 |
Seal, Impeller Housing Plate. |
| 77 |
0322302 |
SEAL, Adapter to frame |
| 78 |
0333592 |
THRUST BUSHING |
| 81 |
0435027 |
CUP & PLATE This part replaces 0330380. |
| 81 |
0435526 |
CHROME CUP & PLATE KIT This part replaces 0330383. |
| 82 |
0435485 |
IMPELLER HOUSING ASSY. This part replaces 0395040. |
| 83 |
0332000 |
SEAL RING |
| 86 |
0326785 |
WASHER |
| 87 |
0389019 |
PROP, 14-1/2 x 23 SST |
| 87 |
0389923 |
PROP, 14-1/2 x 21 SST |
| 87 |
0389924 |
PROP, 14-1/2 x 19 SST |
| 87 |
0389925 |
PROP, 15 x 16 SST |
| 87 |
0390725 |
PROP, 14 x 25 SST |
| 87 |
0390831 |
PROP, 14-1/2 x 14 SST |
| 87 |
0391201 |
PROP, 14-1/2 x 19 |
| 87 |
0391202 |
PROP, 14-1/2 x 21 |
| 87 |
0391203 |
BEARING ASSY,Rear,std |
| 87 |
0391290 |
PROP, 15 x 17 SST |
| 87 |
0391535 |
PROP, 15-1/2 x 15 |
| 87 |
0391536 |
PROP, 15-1/2 x 13 |
| 87 |
0765187 |
PROPELLER, WDEX Models This part replaces 0391200. |
| 91 |
0435526 |
CHROME CUP & PLATE KIT This part replaces 0395059. |
| 92 |
5006373 |
GEARCASE SEAL KIT This part replaces 0396353. |
| 93 |
5001594 |
WATER PUMP REPAIR KIT This part replaces 0395060. |
| 0398132 |
0398132 |
GEARCASE ASSY., Complete |
| 0398133 |
0398133 |
GEARCASE ASSY., Complete |
