| Ref | Part Number | Description |
|---|
| 1 |
511000757 |
Trunk |
| 2 |
511000528 |
Bracket |
| 3a |
511000568 |
Deep Black Trunk Cover |
| 3b |
XXX |
Not Available As Spare Parts |
| 3c |
XXX |
Not Available As Spare Parts |
| 4a |
511000592 |
RADIATOR COVER - Call your local BRP dealership |
| 4b |
XXX |
Not Available As Spare Parts |
| 5 |
XXX |
Not Available As Spare Parts |
| 6 |
511000483 |
RH TUNNEL RAIL - Call your local BRP dealership |
| 7 |
293150104 |
Pop Rivet 3/16" |
| 8 |
520000889 |
Anchor Link |
| 9 |
250000767 |
Torx Truss Screw M6 X 12 This part replaces 250000325. |
| 10 |
511000484 |
LH TUNNEL RAIL - Call your local BRP dealership |
| 11 |
293150104 |
Pop Rivet 3/16" |
| 12 |
520000889 |
Anchor Link |
| 13 |
250000767 |
Torx Truss Screw M6 X 12 This part replaces 250000325. |
