| Ref | Part Number | Description |
|---|
| 10ab |
250300027 |
Clinch Stud M6 X 20 |
| 10ac |
232561414 |
Elastic Stop Nut M6 |
| 10ad |
250000535 |
Torx Screw M8 X 55 |
| 10ba |
518324874 |
RH Reinforcement |
| 10ba |
518324875 |
LH Reinforcement |
| 10bb |
518325955 |
RH SLIDE BRACKET - Call your local BRP dealership |
| 10bc |
518325956 |
LH Slide Bracket |
| 10bd |
518325973 |
RH Rear Base |
| 10be |
518325974 |
LH Rear Base |
| 10bf |
518325159 |
RH ROLLER - Call your local BRP dealership |
| 10bh |
250300038 |
Clinch Stud |
| 10bj |
250300027 |
Clinch Stud M6 X 20 |
| 10bk |
518326656 |
Seal |
| 10bn |
293150144 |
Stavex Rivet |
| 10br |
518327105 |
Rear Cap |
| 10bt |
390909200 |
Avex Rivet |
| 10bu |
293730042 |
Full Moon Dart 5 mm |
| 10bv |
293150203 |
Rivet Avibulb 3/16 |
| 10bw |
390909100 |
Avex Rivet |
| 10bx |
293150144 |
Stavex Rivet |
| 10by |
293150146 |
Henrob Rivet |
| 10bz |
293150266 |
Ornit Rivet 6,5 X 14.5 This part replaces 293150147. |
| 10ca |
293150174 |
Hemlock Rivet, 6.4 mm |
| 10cb |
518326961 |
U-Attach |
| 10cc |
293150266 |
Ornit Rivet 6,5 X 14.5 This part replaces 293150147. |
| 10cd |
250000534 |
Tork Screw M6 X 16 |
| 10ce |
233061414 |
Hex. Flange Nut M6 |
| 10n |
518325559 |
RH Engine Support |
| 10q |
518326820 |
LH Stirup |
| 10t |
518326960 |
Support |
| 10v |
250000536 |
Tork Screw M6 X 18 |
| 10w |
250200039 |
Flat Washer |
| 10x |
250000958 |
Panel Nut M5 X 0.8 |
| 30 |
390402400 |
Pop Rivet 3/16" |
| 100 |
293150148 |
Rivet Magna-Grip 6,4 X 50,8 |
| 110 |
293150149 |
Collar Huck Magna-Grip 6.4 |
| 120 |
518325782 |
RH Deflector, Black Polypropylene |
| 130 |
518325783 |
LH Deflector, Black Polypropylene |
| 140 |
293150104 |
Pop Rivet 3/16" |
| 150 |
207561244 |
Hex. Flange Screw M6 X 12, Scotch Grip |
| 170 |
293150174 |
Hemlock Rivet, 6.4 mm |
| 1300a |
518326611 |
Black Rear Bumper, 154" |
| 1300b |
520000965 |
Black RH Cap |
